Wear Resistant Steel Plate NM500 XAR400 AR500 HARD500
Product Description
| Standard | GB,ASTM,JIS,DIN,EN |
| Grade |
GB:NB300,NM360,NM400,NM450,NM500,NM550 ASTM:AR360,AR400F,AR400,AR500,AR500F JIS:HARD400,HARD450,HARD500,HARD600 DIN:XAR400,XAR450,XAR500,XAR600 SWE:HARDOX400,HARDOX450,HARDOX500,HARDOX600 |
| Thickness | 0.3~300mm |
| Width | 100~3500mm |
| Length | 1m~2m or as required |
| Application |
Heavy wear platforms Earth moving machinery Mining industry machinery Industrial hoppers,funnels and feeders |
Delivery condition: quenched or quenched and tempered (see paragraph “Heat treatment”).
Mechanical properties
Hardness at room temperature in the delivery condition: 370 - 430 HBW
The Brinell hardness shall be determined in accordance with DIN EN ISO 6506. The hardness shall be measured roughly 1 mm (0.039 in.) below the surface of the plate.
Plate thicknesses up to 35 mm (1.378 in.) will also feature a core hardness ≥ 90 % of the minimum hardness.
Typical carbone quivalent and strength values, typical of 15mm(0.591in.) plate thickness
Carbon equivalent CET in % [CET = C + (Mn + Mo) / 10 + (Cr + Cu) / 20 + Ni / 40] : 0.32
Carbon equivalent CE in % [CE = C + Mn / 6 + (Cr + Mo + V) / 5 + (Ni + Cu) / 15] : 0.51
Yield strength in MPa (ksi) *) : 1000 (145.0)
Tensile strength in MPa (ksi) *) : 1250 (181.3)
Elongation at fracture A in % : 10
Impact energy for plates up to 35 mm (1.378 in.) thickness at - 20 °C (- 4 °F) in the state of delivery condition: min. 27J (20 ft lbf) (transverse)
