Help Center20W Portable Fiber Laser Marking Machine for Metal and Non-metal Material
Related Products
-
30W Portable Fiber Laser Marking Machine for Metal and Non-metal MaterialUS$ 2500 - 5000MOQ: 1 Set -
High Quality Desktop Fiber Laser Marking Machine Laser MarkingUS$ 2500 - 5000MOQ: 1 Set
-
High Quality Desktop Fiber Laser Marking Machine Laser Marking 30WUS$ 2500 - 5000MOQ: 1 Set
-
20W Laser Printer/Fiber Laser Marking Machine for MetalUS$ 2500 - 5000MOQ: 1 Set
-
30W Laser Printer/Fiber Laser Marking Machine for MetalUS$ 2500 - 5000MOQ: 1 Set
| machine model | JX-DTBX-Y20 | JX-DTBX-Y30 |
| laser power | 20W | 30W |
| laser wavelength | 1064nm | 1064nm |
| fiber length | 2.5m | 2.5m |
| laser unit using life | 100,000 hours | 100,000 hours |
| marking speed | ||
|
Character marking speed and production line speed depend on material , character size and desired marking quality |
Character marking speed and production line speed depend on material , character size and desired marking quality |
|
| marking speed | 3-5 digital(2*3mm)/ 0.01s | 5-8 digital(2*3mm)/ 0.01s |
| marking depth | 0.01-0.2MM | 0.01-0.5mm |
| min. line width | 0.01MM | 0.01MM |
| min. character height | 0.2MM | 0.2MM |
| marking filed |
(110*110mm (focal length f =160mm) |
(110*110mm (focal length f =160mm) |
| Optional | Optional | |
| 175mm lens | 175mm lens , 250mm lens | |
| power supply | 220V 50HZ/2A | 220V 50HZ/2A |
| power consumption | 800W/ HOUR | 1000W/HOUR |
| cooling | AIR | AIR |
| positioning | Visible red power | Visible red power |
| operation temperature | 25℃ to 28℃ | 25℃ to 28℃ |
| humidity | 5% to 75% (no condensation) | 5% to 75% (no condensation) |
Shanghai Jiaoxi Laser Equipment Co.,Ltd is a professional manufacturer of Laser Marking Machine ,Laser Cutting Machine and CNC ROUTER ,Located in Shanghai
Baoshan industrial zone,it has a modern R & D center and manufacturing plant,since it was established ,it has continued to train and recruit talents through cooperation with colleges and brought a large number of enterprising and leading elites of the industry
Our company mainly products including laser marking machine ,CO2 laser cutting machine and cnc router etc , widely used in metal and non-metal field ,for example hardware ,integrated circuit chips ,
industrial bearings ,variety of auto parts ,hardware tools ,wire and cable ,mould,garment leather and craft gifts etc .in line with our advanced philosophy ,excellent products ,down to earth service,along with our strong R&D and production capacity ,wide social cooperation as well as efforts of our every employee,some machines are exported to the Europe, America, Singapore, Vietnam, India and Bangladesh etc .
Manufacturer the world first-class laser equipments is the enternal pursuit of jiaoxi laser
