KSP-7 Shotcrete Machine
Small Shotcrete Machine Wet Shotcrete Machine Price
Shotcrete Machine Features:
1.KSP-7 Rotor Type Wet Shotcrete Machine for Sale
2.KSP series wet shotcrete machine includes driving device, rotor assembly, sealing system, vibration hopper, air system, spraying system, accelerator conveying system, electric control system.
ncrete mixture gets well mixed, water and cement ratio is accurately controlled.
4.quicker cement hydration, fewer dusts, lower rebound rate, good mixing uniformity and high concrete strength.
5.reasonable structure, stable performance, convenient operation and maintenance, long service life.
6.KSP-5,KSP-5D,KSP-7,KSP-7D,KSP-9,KSP-9D are optional models, customized model is available.
Shotcrete Machine Application:
1.for spraying half wet or wet concrete.
2.widely used for tunnel, culvert, subway, hydroelectric works, underground works and mine laneway.
Shotcrete Machine Technical Parameters:
| Model | KSP-7 (electric motor) |
| Capacity | 7m³/h |
| Conveying distance | 35m(WET)/200m(DRY) |
| Max. aggregate size | 15mm |
Concrete slump | 8~15cm |
| Conveying Pipe ID. | 51mm/64mm |
Rebound rate | ≤10%(on average ) |
| Rated working pressure | 0.3-0.6Mpa |
| Air consumption | 9-10m³/min |
| Motor power | 7.5kw |
| Max. Pump discharge of accelerator | 35-200L/h |
| Voltage rating of accelerator | 0.6Mpa |
| Voltage | 380V/660V |
| Dimension | 2050*950*1180(mm) |
| Weight | 1200kg |
Shotcrete Machine Detailed Images:
|
|
KCPZ series Dedusting Shotcrete Machine * Dust Removal * Electric Motor * KCPZ-5; KCPZ-6; KCPZ-7
| KPZ series Dry Shotcrete Machine * Electric Motor * KPZ-3; KPZ-4; KPZ-5; KPZ-7; KPZ-9 |
|
|
KPZ-A series Dry Shotcrete Machine * Air Motor * KPZ-3A; KPZ-4A; KPZ-5A; KPZ-7A; KPZ-9A | KPZ-D series Dry Shotcrete Machine * Diesel Engine * KPZ-3D; KPZ-4D; KPZ-5D; KPZ-7D; KPZ-9D |
|
|
KSP series Wet Shotcrete Machine * Electric Motor * KSP-5, KSP-7, KSP-9 | KSP-D series Wet Shotcrete Machine * Diesel Engine * KSP-5D, KSP-7D, KSP-9D |
Henan Coal Scientific Research Institute Co., Ltd. was established in March 1979. In 1999, it was ranked among the first batch of 242 coal research institutes, and implemented localized management by Henan Province. In 2006, it was transformed successfully into a scientific and technological enterprise, and renamed officially as Henan Coal Research Institute Co., Ltd.
Achievements: As one of the standard setting unit of national shotcrete equipment industry, the company has obtained more than 170 research and development achievements, more than 110 technical consulting services, 82 technology awards and15 national invention patents and utility model patents.
Application: mining well project, hydropower engineering, highway (railway) tunnel, subway engineering, bridge and slope maintenance, air-raid shelter construction, municipal construction, environmental greening project, blast-furnace refractories spraying, etc.
Main Products: wet/dry shotcrete machine, concrete/shotcrete pump, grouting pump, cement pump, mortar pump, slurry pump, hose pump, cement/concrete mixer, concrete foaming machine, plastering machine etc.
---Shotcrete Machine, Gunite Machine, Concrete Spraying Machine
1. Q: Which shotcrete machine should we choose?
A: To recommend the most suitable model, please tell us:
- Material: dry / damp mixture, or ready mixed wet mixture
- Capacity: 3m3/h, 4m3/h, 5m3/h, 6m3/h, 7m3/h, 9m3/h
- Delivery distance (horizontally / vertically):
- Driven type: electric motor, pneumatic motor, diesel engine
2. Q: What is the vulnerable part? How many spares should we prepare?
A: After long-time running, the rubber plate, steel plate, rubber cavity, spraying nozzle, delivery hose may get worn. We will offer some spares for free.
Referring to the service life of each part, we will put a rough estimate of requested spares according to your project scale -how many cubic meters you will spray.
3. Q: Can we have customized model?
A: Yes. Customized production and OEM production are available according to your actual requirements.
4. Q: Do i need technical skills to operate this machine?
A: Yes. Please read the Operation Instruction for some basic technical skills before operating this machine, and contact us if any operation procedure is unclear.
5. Q: What should we do if there are some problems with the machine?
A: The Operate Instruction will help with routine maintenance and common problems.
Also, you can contact us for technical instruction by email, instant messenger or live video etc.
6. Q: What is the lead time?
A: 1 week for sample model, 2~3 weeks for customized model. It depends for mass production.
7. Q: How about the package?
A: The machine will be wrapped by plastic film and packed by fumigation-free wooden case along with spare parts.
8. Q: How to place an order?
A: Both online order and offline order are acceptable.
It is suggested to place online order with a Trade Assurance to get full protection for first order.
9. Q :How to pay for this order?
A: Generally, TT, 30% deposit 70% before shipment;
L/C at sight (high bank charge, not suggest, but acceptable);
100% TT in advance (especially for small amount and spare parts etc.)
