KS-8 Concrete Pump
Secondary Construction Filling Concrete Pump Reinforcement Grouting Concrete Pump
Features:
1.Small size, compact structure, convenient operation and movement.
2.Full hydraulic system, stable performance,long pumping distance.
3.S tube distribution valve, pumping larger aggregates mortar/concrete.
Application: Concrete Pump
1. Pumping wet-mixed mortar for high buildings and secondary structure construction.
2. KS series concrete pump is widely used for secondary construction filling, reinforcement grouting, fillback grouting and bolt supporting in floor heating engineering, roofing, high-rise building walls, reservoirs, hydropower stations, ports, docks, foundation treatment, soft foundation, tunnels, subways, mining construction etc.
Specifications: Concrete Pump
Model |
KS-8 mortar pump |
Max capacity |
5~7 m³ |
Working theory |
S valve |
Feeding height |
0.7m |
Max aggregate size |
5~20mm |
Max pressure: working pressure |
15MPa: 10MPa |
Hydraulic oil cooling type |
Air cooling |
Max vertical distance |
15m |
Max horizontal distance |
50m |
Delivery pipe ID. |
65mm~80mm |
Motor power |
11kw |
Weight |
600kg |
Dimensions |
1800*700*1100mm |
Details:
Henan Coal Scientific Research Institute Co., Ltd. was established in March 1979. In 1999, it was ranked among the first batch of 242 coal research institutes, and implemented localized management by Henan Province. In 2006, it was transformed successfully into a scientific and technological enterprise, and renamed officially as Henan Coal Scientific Research Institute Co., Ltd.
Achievements: As one of the standard setting unit of national shotcrete equipment industry, the company has obtained more than 170 research and development achievements, more than 110 technical consulting services, 82 technology awards and15 national invention patents and utility model patents.
Application: mining well project, hydropower engineering, highway (railway) tunnel, subway engineering, bridge and slope maintenance, air-raid shelter construction, municipal construction, environmental greening project, blast-furnace refractories spraying, etc.
Main Products: wet/dry shotcrete machine, concrete/shotcrete pump, grouting pump, cement pump, mortar pump, slurry pump, hose pump, cement/concrete mixer, concrete foaming machine, plastering machine etc.
1.Q: Which model should we choose?
A: Many models are provided for your choice. Before suitable model is recommended, please tell us the application, materials, output and pressure you want.
2. Q: Can we have customized model?
A: Yes. Customized model is available according to your actual requirements.
3. Q: Do i need technical skills to operate this machine?
A: Yes. Please read the Operation Instruction for some basic technical skills.
And, we provide online and onsite technical training if necessary.
4.Q: What should we do if there are some problems with the machine?
A: You can refer to the Operate Instruction or call our 24-hour service hotline.
Also, our engineers are available to service overseas.
5.Q: What is the lead time?
A: 1 week for sample model, 2~3 weeks for customized model. It depends for mass production.
6.Q: How about the package?
A: We have fumigation-free wooden case to protect the machine from damage during the long-distance delivery.
7.Q: How to place an order?
A: Both pnline order and offline order are acceptable.
It is suggested to place online order with a Trade Assurance to get full protection for this order.
8.Q :How to pay for this order?
A: Generally, TT, 30% deposit 70% before shipment;
L/C at sight (high bank charge, not suggest, but acceptable);
100% TT in advance (especially for small amount and spare parts etc.)
Tel: 0371-63844654/67836512
Fax: 0371-63930764
Mobile: +86 18236882465 (Whatsapp/Wechat)
Skype: zhang-angela
QQ: 2561389251
Email: angela_zhang @
zhangting097 @
