Help CenterDigital Plastic Pulses LGSG Water Flow Meters Pulse Sensor
Related Products
-
Brass Body Pulse Multi Jet Water Flow Meter Pulse SensorUS$ 16 - 69MOQ: 1 Piece -
Digital LXSG Brass Body Reed Switch Pulse Water Flow Meter SensorUS$ 16 - 69MOQ: 1 Piece
-
Plastic Body Pulse Output Reed Switch Water MetersUS$ 6.8 - 50.5MOQ: 1 Piece
-
Plastic Pulse Output Reed Switch Remote Reading Water MetersUS$ 6.8 - 31MOQ: 1 Piece
-
Manifold Superior Quality Plastic Pulses Mult Jet Water Meter for ZimbabweUS$ 6.8 - 31MOQ: 1 Piece
Products Details:
More Details:
Features:
· All the plastic raw material is 100% new material, not any
second-hand material.
· High working pressure can afford PN16.
· Magnetic Drive, Lower transmission resistance.
· Magnetic shield, for external magnetic field protection.
· Sealed dry register ensures long time clear reading.
· External regulating device.
Accressories: 2pcs coupling, 2pcs coupling nuts and 2pcs washers.
Working Conditions:
· Water temperature: 0.1℃~40℃ for cold water meter.
· Water pressure : ≤1.6Mpa (16 bar).
Maximum Permissible Error:
· In the lower zone from qmin inclusive up to but excluding qt
is ±5%.
· In the upper zone from qt inclusive up to and including qs is
±2%.
Dimension:
Overall Dimension And Weight:
| DN(mm) | 15 | 20 | 25 | 32 | 40 | 50 | 50 |
| Size(inch) | 1/2" | 3/4" | 1" | 1-1/4" | 1-1/2" | 2" | 2" |
| Length(L) | 165/190 | 190 | 260 | 260 | 300 | 300 | 280 |
| Width(W) | 99/104 | 98 | 103.5 | 103.5 | 125 | 125 | 160 |
| Height(H) | 116/121 | 117 | 124 | 124 | 162 | 162 | 187.5 |
| Connecting Thread D | G3/4B | G1B | G11/4B | G11/2B | G2B | G21/2B | Flange Connect |
| Weight(kgs) | 1.65 | 1.79 | 1.85 | 2.68 | 5.25 | 7.25 |
Technical Data:
| DN (mm) | 15 | 25 | 32 | 40 | 50 | |
| Size (inch) | 1/2" | 1" | 1-1/4 | 1-1/2" | 2" | |
| Q4(l/h) | 3125 | 7875 | 12500 | 20000 | 31250 | |
| Q3(l/h) | 2500 | 6300 | 10000 | 16000 | 25000 | |
| R=80 | Q2 (l/h) | 50 | 126 | 200 | 320 | 400 |
| Q1 (l/h) | 31.25 | 78.75 | 125 | 200 | 250 | |
| R=100 | Q2 (l/h) | 40 | 100.8 | 160 | 256 | 400 |
| Q1 (l/h) | 25 | 63 | 100 | 160 | 250 | |
| R=125 | Q2 (l/h) | 32 | 80.64 | 128 | 204.8 | 200 |
| Q1 (l/h) | 20 | 50.5 | 80 | 128 | ||
| R=160 | Q2 (l/h) | 22.5 | 63 | 100 | 160 | 400 |
| Q1 (l/h) | 15.62 | 39.37 | 62.5 | 100 | 250 | |
| Max. Reading (m3) | 99,999 | 99,999 | 99,999 | 99,999 | 99,999 | |
| Min.Reading (Liter) | 0.05 | 0.05 | 0.05 | 0.05 | 0.05 | |
| Max.Pressure (Bar) | 16 | 16 | 16 | 16 | 16 | |
| Pressure Loss | 63 | |||||
| Max.Temperature | T=50 /90 | |||||
| Pulse Output Option | Vmax=24V | |||||
| Imax=100mA | ||||||
| Pmax=2W | ||||||
More Types:
| Magnet Position | Liter /Pulse |
| * 0.0001 | 1 |
| * 0.001 | 10 |
| * 0.01 | 100 |
| * 0.1 | 1000 |
Packaging Detail: Pallets without fumigation or wooden box
Company Information:
Our factory build up since 1966, with more than 50 years experience in the line for water meter technology and manufacture. We provide OEM services for many famous brand, from German and Italy, for example, Zenner and B Meters. We also export the mechanism and spare parts for many countries, like Egypt, Turkey and so on. So we have enough confidence to believe that our product can meet with your request.
Warranty
All meters will be guaranteed against defects in workmanship and materials for a period of one (1) year from the date
of acceptance. Defective meters or parts discovered within this period shall be replaced without charge upon return
to the SH-MECH Meters.
Technical data conform to international standard ISO 4064, and we have more water meter types,such as:
