IH series chemical centrifugal pump for pumping sulfuric acid
Scope of application
1. IH model sulfuric acid pumps are the series of products designed according to ISO international standards. It is mainly composed of pump body, impellers, seal rings, impeller nuts, pump cover, seal parts, intermediate support, spindle, suspended parts and so on.
2. To make it convenient to disassemble, the prolonged coupling is designed, so that it is unnecessary to disassemble the Coupled input & output pipes during check and maintenance, only by disassembling the intermediate coupler of the prolonged coupling, users are able to screw out rotor part.
3. The shaft seal is mechanical seal generally, use of imported titanium rings and carbide mechanical seals and high temperature materials, corrosion resistant, no leakage.
4. The pump is connected with the motor through flexible coupling, the pump rotation direction, from the motor end, is clockwise rotation.
Application
The IH type pump is applied to transport various corrosive medium or medium in which pollution is forbidden in such industries as chemical engineering, petroleum, metallurgy paper-making, food, medicine, fiber, etc.
1. Widely applicable for petrochemical.
2. Widely applicable for metallurgy.
3. Widely applicable for synthetic fiber.
4. Widely applicable for pharmacy.
5. Widely applicable for desalination of seawater
Parameter of LQB heat insulation pump for bitumen
Operating Data
Outlet Diameter:125-400mm
Capacity: 12.5-400m3/h
Head: 5-125m
Rotation Speed: 1450r/min
Power: 0.55-75kW
Product Show
Package& Transportation
FAQ
