pump manufacturer 2bv 50hz water circulating vacuum pump
| INFORMATION OVERVIEW | |
|
Basic information: 1) Model: EVP brand 2BV5-131 liquid ring vacuum pump 2) Ultimate vacuum pressure: 33 mbar (abs.) 3) Max suction capacity: 400m3/h @50hz, 480m3/h @60hz |
|
Packaging Details: Standard woonden case suitable for all countries Packing dimension: L x W x H= 950 x 480 x 550 mm Net weight / Gross weight: 195 kg / 217 kg | |
|
Certificates: ISO9001:2000 / SGS / CE Lead Time: Have many models in stock, if not, it is about 20 days when less than 5 units, about 35 days when less than 10 units. If urgent, please tell us. |
More Items, please scan:
|
SPECIFICATIONS: 2BV Liquid Ring Vacuum Pump | |||||
|
Model |
Max.Suction capacity m³/h |
Inlet &outlet |
Feed water inlet |
Motor power kw 50Hz |
Pump speed r.p.m |
Operating liquid flow rate L/min |
Noise dB(A) |
Weight kg |
2BV2-060 |
27 |
G1" |
G3/8" |
Y90S-2-0.81 |
2840 |
2.5 |
62 |
31 |
2BV2-061 |
52 |
G1" |
G3/8" |
Y90S-2-1.45 |
2840 |
2.5 |
65 |
36 |
2BV2-070 |
80 |
G1.5" |
G3/8" |
Y100L-2-2.35 |
2860 |
3 |
66 |
56 |
2BV2-071 |
110 |
G1.5" |
G3/8" |
Y112M-2-3.85 |
2880 |
4.7 |
72 |
60 |
2BV5-110 |
165 |
DN50 |
G1/2" |
Y112-4-4KW |
1440 |
7.2 |
63 |
105 |
2BV5-111 |
230 |
DN50 |
G1/2" |
Y132-4-5.5KW |
1440 |
8.8 |
68 |
126 |
2BV5-121 |
280 |
DN65 |
G3/4" |
Y132-4-7.5KW |
1440 |
11 |
69 |
149 |
2BV5-131 |
400 |
DN65 |
G3/4" |
Y160-4-11KW |
1460 |
16 |
73 |
195 |
2BV5-161 |
500 |
DN80 |
G3/4" |
Y180-6-15KW |
970 |
22 |
74 |
320 |
