Miniature Infrared Temperature Senor DOB20-M500C

Small in size, extremely accurate and very easy to use.

General Specifications
Temperature Range: 0~500℃ （See To Order chart ）
Supply Voltage:  24 Vdc
Output: 4 to 20 mA
Field of View:  20：1
Accuracy: ±2°C or 1%, whichever is greater
Repeatability: ±0.5°C or 0.5%, whichever is greater
Emissivity Setting Range: pre-set to 0.95
Emissivity Setting Method: User Adjust  emissivity
Response Time: 100 ms
Spectral Range: 8 to 14 μm
Maximum Current Draw: 25 mA
Construction: Stainless Steel 304
Dimensions: ø18 x length42 mm
Mounting: two mounting nuts
Cable Length: 2m as standard (custom lengths also available)
Weight: 400g with 2 m(7') cable
Environmental Rating: IP65
Ambient Temperature Operating Range: 0 to 50°C (32 to 122°F)
4-wire , 3-wire or 2-wire ( freely)

To Order
Model  DOB20-M100C   DOB20-M200C   DOB20-M300C   DOB20-M500C   DOB20-LM500C
Range   0-100℃                   0-200℃           0-300℃               0-500℃          -20-500℃
