Mold number ：GP-2103（Three stations）
Product name ：Phone key button life tester
Summary description ：
First part 、application ：
This machine is used to test key button ( silicone button,Metal dome dome button And communication products The service life,With the number of automatic memory,Power down memory,The cumulative number of life,Reach the set number of automatic shutdown and other functions.Another new force control,Actual life assessment and other functions.
Second part :Main technical specifications
1.A whole station,There are 3 test stand-alone stations,Can test 3 piece product,With a control system,A set of control systems controls the independent testing of three piece product.Set one screen for each condition.Need to see the test conditions and results to convert a picture,That does not affect mutual testing,Equivalent to independent control.
2.Each sample can be tested 6 key button (Not pressed at the same time,Is a continuous action,For example, press the six keys in sequence of 1-2-3-4-5-6 for one test cycle)
3.The controller can control the cylinder depression time,such as test switch machine, simulate the actual situation of the key test,Press for a few seconds to start the boot action.After waiting for the machine to start up,Then press it again to shut down, wait a few seconds for shutdown,The time required for each action can be adjusted according to different samples.(The test head drops,Rise and other hold times can be adjusted)。
4.The controller is PLC control。
5.Test speed ：reach 10-60 times/minute。
6.Testing frequency ：continuous key test 1000000 times 。
7.Key button pressure：0.1N～20N。
8.Size ：370×800×510mm
9.weight ：55kg
10.power supply ：AC220V/50HZ。
E-mail : gopoint@gopoint.com.cn / 2593988119@qq.com
Cell phone/whatsapp ：8618138867802
Contact : Rice Hu
