Mold number：GP-2102（1 work place）
Product name：(one station) Phone flip life tester
Summary description：
First part 、application
This product suitable Cell phones and other products flip open and close Life test。
Second part 、Technical specifications：
1、Flip cycle：6～60times/Minute
2、Test phone specifications：,one times can test 1 piece phone .Its specifications are as follows ：
a)length 50～120mm
b)width 30～75mm。
c)thickness 15～35mm
3、Clamshell axis Adjustment range：Y to 10mm，z to 20mm；
4、Start method：Stepping motor;
5、Control System: Stepping motor start cycle,Speed of movement,Opening and closing angle;
a)Touch screen setting and display count value;
b)PLC Control stepper motor start and stop;
c)The phone cover is not in place or Count value to alarm and shutdown;
6、Dimensions ：around 445X580X460mm;
7、weight ：around 50kg；
8、power supply：AC220V/60HZ；
