HZ-200YY hydraulic water well drilling rig/small water well drilling rigs for sale
- 100 Set / Sets per Month
- qingdao
- T/T L/C D/P D/A
- 7 days
-
China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
-
100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
-
HY-50H Small Domestic Hydraulic Water Well Drilling Rig of China
-
50m Depth Core Drilling Rig Portable Diamond in Mountain
-
TSP core bit, BQ NQ HQ PQ core drill bits, HWL, wireline core barrels, diamond coring bits, hard formation, deep hole rock core recovery
-
1.5M 3M inner tube assembly, wireline core barrels, head assembly, impregnated diamond drilling, hard formation coring, deep hole rock core recovery
Product Details
| Brand Name: | huaxiamaster | Place of Origin: | China | Model Number: | HZ-200YY |
| Type: | Core Drilling Rig | Certification: | ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
| Warranty: | yes | Weight: | 975kg | Dimension(L*W*H): | 1600*1500*1400 |
| Power Type: | Diesel | Voltage: | 220V | Usage: | Water Well |
| Condition: | New | Power(W): | 22HP |
Product Description
1.Applications of HZ-200YY hydraulic water well drilling rig
HZ-200YY water well drilling rig is mainly used for civil water wells,geological general investigation and exploration, road and tall building foundation exploration, holes in concrete structure, river levees, ground temperature central air-conditioner.
2. Features of HZ-200YY hydraulic water well drilling rig
· the highest speed can reach 1045r/min with 5 gears, which improves drilling efficiency
· adopted 53*59 drilling rod, which has high rigidity and strong delivery torque.
· equipped with taper clutch, made the machine easy to operate and free of maintenance.
· using large module planetary gear and adding supporting frame, which highly increased hoisting and braking ability of the winch.
· vertical spindle are fixed by four groups of bearings to ensure that the core machine is rigid enough for gravel layer and other complex geological conditions.
3. Parameters of HZ-200YY hydraulic water well drilling rig
Max open hole diameter | 300mm |
End hole diameter | 75mm |
Drill rod diameter | 60mm |
Drilling angle | 90 |
Drill weight (without power) | 975kg |
Triangle conveyer belt | B950 * 4; B1700 * 3 |
Main machine moving distance | 300mm |
Power | Diesel engine 22HP |
Electric motor 15kw | |
Spindle | |
Spindle speed | 64/128/287/557r/min |
Spindle stroke | 450mm |
Hoist | |
Max. lifting capacity | 2400kg |
Single line lifting speed | 0.41/0.82/1.64 m/s |
Wire rope diameter | 13mm |
Wire rope length | 35m |
Reel diameter | 140mm |
Hug floodgate diameter | 260mm |
Hug floodgate belt width | 70mm |
Mud pump | |
Type | Horizontal single-urn twin-action |
Displacement | Diesel engine 170L/min |
Electric motor 150L/min | |
Maximum pressure | 3mpa |
Work pressure | 1.5mpa |
Inlet pipe diameter | 40mm |
Outlet pipe diameter | 30mm |
Triangle conveyer belt | B1728mm |
