Help CenterXY-150 Hydraulic Water Well Drilling Rig/Water Well Drilling Rig Dor Sale in Japan
Related Products
-
China Sale of High Quatity XY-180 Hydraulic Water Well Drilling Rig /bore Hole Drilling RigUS$ 1500 - 1800MOQ: 1 Set -
XY-200 Hydraulic Water Well Drilling Rig /Water Well Drilling Rig Dor Sale in JapanUS$ 1500 - 1600MOQ: 1 Set
-
XY-3 Hydraulic Water Well Drilling Rig /water Well Drilling Rig Price/Water Well Drilling Machine PortableUS$ 1600 - 1800MOQ: 1 Set
-
XYX-3 Wheeled Hydraulic Water Well Drilling Rig /Water Well Drilling Machine PortableUS$ 1200 - 1600MOQ: 1 Set
-
XYD-3 Crawler Hydraulic Water Well Drilling Rig/well Drilling RigUS$ 1500 - 1600MOQ: 1 Set
1.Applications of XY-150 hydraulic water well drilling rig
· geological survey
· geophysical exploration
· road and high-rise building foundation exploration
· water wells
· blasting holes and other drilling projects
2. Parameters of XY-150 hydraulic water well drilling rig
Drilling depth(m) |
150 |
Maximum opening diameter（mm） |
219 |
The final hole diameter（mm） |
73 |
Rod diameter（mm） |
42/50 |
Spindle speed (r/min) |
140/295/470/790/1010 |
Spindle stroke（mm） |
450 |
Hoisting capacity (kn) |
14 |
Steel wire diameter（mm） |
9.3 |
Maximum pressure (mpa) |
1.2 |
Working pressure (mpa) |
0.7 |
displacement（l/min） |
150 |
Hydraulic pump pressure (mpa) |
1.2 |
Hydraulic pump rotation speed (r/min) |
1800 |
Matched driving power (diesel engine and motor) |
S1105 diesel engine and 11kw motor |
Shandong Master Machinery Group Co.,Ltd.
Sales Manager:Candice Cheng
Tel:0086-537-2335787
Mob: 0086-18865479502
Wechat:008618865479502
Whatsapp:008618865479502
QQ:1447852867
E-mail:sale02@huaxiamaster.com
Website:
Send Inquiry to This Supplier
