Overview

The coalescing separator contains two kinds of filter elements, namely: a polymer filter and a separation filter.The coalescing filter has the dual function of filtering impurities from the oil and agglomerating moisture, and is an important functional energy component of the filter separator. The Pall series of coalescing cartridges meet the needs of a wide range of filter separators used in fixed and mobile fueling facilities.

Features are as follows:

1. Filter paper with multi-layer composite structure, high filtration precision;

2, carefully set and specially treated glass fiber layer, good coalescence effect.

3, the flow density is large, reducing the size of the fine filter;

4. Large pollution capacity and long service life;

5, the full range of specifications, to meet the needs of a variety of fine filters.

Product Performance:

UTERS Replace PALL Coalescing  filter Element CC3LGA7H13

PALL Diesel filter Element CC3LGA7H13

PALL Coalescing natural gas filter Element CC3LGA7H13

1. Starting pressure difference:<0.03MPa

2. Maximum allowable working pressure difference: 0.15 MPa

3. Maximum working temperature: 80°C

4. Dehydration capacity: up to 15% water content

5. Filter structure strength: >0.7 MPa

6. Filtration accuracy: up to 1μm

7. Free water content at the outlet:<10PPm (up to the latest API standards)

8. The coalescing filter element has the dual function of filtering impurities and agglomerating moisture from aviation kerosene, and is an important functional component of the fine filter.

The coalescing separation filter cartridge meets the needs of a variety of fine filters used in fixed mobile fueling facilities.

Application:

1. Aviation fuel, gasoline, kerosene, diesel;

2. Liquefied petroleum gas, stone tar, benzene, toluene, xylene, cumene, polypropylene, etc.;

3. Turbine oil and other low viscosity hydraulic oils and lubricating oils;

4, cyclohexane, isopropanol, cycloethanol, cyclohexanone, etc.;

5. Other hydrocarbon hydrocarbon compounds

Quality Standard

ISO 2941------Collapse & Burst Resistant

ISO 2942------Fabrication & Integrity Test

ISO 2943------Material Compatibility with Fluids

ISO 3724------Flow Fatigue Characteristics

ISO 3968------Pressure Drop vs. Flow Rate

ISO 16889------Multi-pass Performance Testing

Frequently Asked Questions

Payment: T/T,Western Union,Money Gram,L/C,D/A,D/P and etc.

Package: Paper boxes;Exported standard wooden boxes or Customized.

Shipment: Choose the most economical transportation method based on the information of the goods:Express door to door;Ship by Sea or air.

Production: 7 work days after payment usually.

Warranty: 12 months after shipment.
