Industrial 200 Liter 500 L Steam Jacketed Cooking Kettle price
Brief introduction of Industrial 200 Liter 500 L Steam Jacketed Cooking Kettle
The machine is specially used for cooking syrup, jam, chilli paste, and other sauce paste. It at the same time has agitating function.
Operation Procedure of JCG-300L Industrial 200 Liter 500 L Steam Jacketed Cooking Kettle
1. Before starting the machine, check the heat transfer oil.
2. Clean the kettle before putting raw material.
3. Open the oil valve before starting machine.
4. Connect the electricity and start the machine. Adjust the temperature to the required temperature(no more than 280℃). Now can begin production.
5. Cut off electricity and close oil valve before tilting kettle.(you can turn hand wheel and make the kettle tilt to discharge raw material).
Technical Parameters of Industrial 200 Liter 500 L Steam Jacketed Cooking Kettle
Model | JCG-300L | JCG-500L |
Capacity | 300L | 500L |
Inner Diameter | 600mm | 1100mm |
External Diameter | 700mm | 1200mm |
Agitator Motor | 1.1kw | 2.2kw |
Heating Tube Power | 27kw | 36kw |
Max Tilting Angle | 90° | 90° |
Mixing Speed | 21-22r/min | 21-22r/min |
Thickness of Steel Plate | Inner layer: 3mm Jacketed Layer: 3mm Cladding Layer: 2mm | Inner layer: 4mm Jacketed Layer: 3mm Cladding Layer: 2mm |
Material | SUS304
| |
Heating Source | Electricity | |
Accessories | 1.Thermograph 2.Electric elements 3.Electric Controller | |
Voltage | 380V,50HZ,three phase(or made by demand) | |
Details pictures of JCG-300L Industrial 200 Liter 500 L Steam Jacketed Cooking Kettle
Service before sale
1, 24 hours online .Your inquiry will be quick reply by email .
Also can go through all questions with you by any online chatting tools (Wechat ,Whatsapp,
Skype ,Viber ,QQ , TradeManager )
2,Professionally and patiently introduction,details pictures and working video to show machine
Service on sale :
1,Test every machine and inspect the machine seriously .
2,Send the machine picture which you order , then packing it with standard export wooden
box after you confirm the machine is ok .
3,Delivery:If ship by sea .after delivery to seaport .Will tell you the shipping time and arrival
time. Finally, send all original documents to you by Express For Free.
If delivery it by Express to your door(DHL, TNT,Fedex, etc) or by air to your airport, Or logistic
to the warehouse which you request . We will tell you the tracking number after delivery.
Service after sale
1, Free insurance for goods
2, 24 hours online to solve any problem . Supply you English manual book and technical
support,maintain and install video to help you solve the problem, or dispatch worker to your
factory.
Questions/Answer |
1,What is the voltage/phase for this machine ? |
220V 50Hz/single phase ,380V 50Hz/three phase , 110V 60Hz/single phase also can made as the clients’ need |
2,What is the Mode of transportation ? |
LCL and FCL by ship ,By Express (DHL,TNT, Fedex etc) ,By air |
3,How long can we get the goods? |
we usually delivery in 3-5 working days, we will inform you shipping time based on your seaport. |
4,How long is the guarantee? |
we promise guarantee as one year for non-human damage factor. |
5,How should I do if meet some trouble while using? |
we can supply English manual book and also take a video for showing how to resolve the problems or dispatch our worker to your factory. |
6,What about Payment term? |
T/T(Telegraphic Transfer ) --30% as prepayment by T/T, after seen the copy of the B/L sent by fax, the balance of 70% should be effected . Western Union ,L/C ,Trade Assurance,Etc. |
7,What’s your MOQ |
1 set |
8, How can i contact with you ? |
You can send inquiry to me . Aslo can contact with me by Cellphone/Wechat / Whatsapp /Viber:0086-15890162785 Skype :nancy-yize,QQ : 3162296161 |
Zhengzhou Yize Machinery CO.,Ltd’s factory was built in 2008, its exporting company wasassessed gold supplier in 2015 by alibaba. It is specialized in the production of food processing machinery, We will supply 100% QC inspection before shipment and 100% guaranteed after sales service.
Top quality machinery is waiting for your choose.
