3.5 Tons Diesel Forklift With CE

3.5 Tons Diesel Forklift With CE thumbnail-1
3.5 Tons Diesel Forklift With CE thumbnail-2
3.5 Tons Diesel Forklift With CE thumbnail-3
3.5 Tons Diesel Forklift With CE thumbnail-4
3.5 Tons Diesel Forklift With CE thumbnail-5
3.5 Tons Diesel Forklift With CE photo-1
3.5 Tons Diesel Forklift With CE photo-2
3.5 Tons Diesel Forklift With CE photo-3
3.5 Tons Diesel Forklift With CE photo-4
3.5 Tons Diesel Forklift With CE photo-5
US$ 7000 - 8500 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Saferlifts
Place of Origin:
China
Model Number:
FD35
Contact Supplier Request Quote Chat Now
Shanghai Saferlifts Machinery Co., Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Saferlifts
Place of Origin China
Model Number FD35
Certification CE SGS
Type Powered Pallet Truck
After-sales Service Provided Engineers available to service machinery overseas
Condition New
Rated Loading Capacity 3500kg
Fork Width 150mm
Fork Length 1200mm
Min. Lifting Height 100mm
Max. Lifting Height 6000mm
Power Souce Diesel Engine

2. Product Description of  3.5 ton diesel forklift



3.5T Diesel Forklift specification

General 1 Model
FD35
2 Power type
Diesl
3 Rated capacity kg 3500
4 Load center mm 500
5 Operator type
Seated
6 Tyre type Front/Rear
Pneumatic
7 Number of wheels(X=driven)) Front/Rear
2 X /2
Dimensions 8 Lifting height mm 3000
9 Free lift height mm 150
10 Fork size LxWxT mm 1070X130X45
11 Mast tilt range F/R
6/12
12 Overall Length(Without fork) mm 2725
13 Overall width mm 1225
14 Mast lowered height mm 2160
15 Mast extended height mm 3290
16 Overhead guard height mm 2090
17 Turning radius(Outside) mm 2450
18 Fork overhang(Wheel center to fork face) mm 498
19 Min.right angle stacking aisle width (Add load length and clearance) mm 2900
20 Wheelbase mm 1700
21 Tread  Front mm 1000
22 Rear mm 970
23 Ground clearance Lowest mm 145
24 Wheel base center mm 140
Performance 25 Speed Travel Full load km/h 18
26 No load km/h 19.5
27 Lifting Full load mm/s 380
28 No load mm/s 450
29 Lowering Full load mm/s 420
30 No load mm/s 460
31 Max.Drawbar Pull Full load/No load kg 1304/1190 1696/1190
32
33 Max.Gradeability Full load/No load % 15/18 15/18
Weight 34 Self weight kg 4750
35 Wheel distribution Full load Front kg 7320
36 Rear kg 930
37 No load Front kg 2040
38 Rear kg 2710
Wheels 39 Tyres Spec Front
28*9-15-12PR
40 Rear
6.50-10-10PR
Brake 41 Brake type Driving brake
Hydraulic
42 Parking brake
Mechanical hand brake

43 Battery Voltage/Capacity V/AH 12/100

44 Transmission Model type
Powershift (Manual)

45 Stage FWD/RVS
1/1 (2/2)

46 Operating pressure Mpa 17.5


Product Tags: diesel forklift , 3.5 tons diesel forklift , 3.5 tons diesel forklift with CE , 3.5 tons diesel forklift with Japan engine , China 3.5 tons diesel forklift with CE , Diesel forklift trucks
