QF-5G Oxygen Cylinder Valve,CGA Cylinder Valve Medical Gas Cylinder Valves ,Gas Valve Type
US$ 1 - 9
MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
SEFIC Gas Valve Type
Place of Origin:
Shanghai, China
Model Number:
QF-5G Gas Valve Type
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CGA870-3 Natural Gas Cylinder Valve,Oxygen Cylinder Valve,Gas Valve TypeUS$ 1 - 9MOQ: 1 Unit -
CGA870-1 Natural Gas Cylinder Valve,Oxygen Cylinder Valve,Gas Valve TypeUS$ 1 - 9MOQ: 1 Unit
-
QF-42 Natural Gas Cylinder Valve,Oxygen Cylinder Valve,CGA Cylinder Valve Seamless Steel Gas Cder ValveUS$ 1 - 9MOQ: 1 Unit
-
CGA580A Wrapped Fiberglass Composite Gas Cylinder Valve CGA Cylinder Valve,Oxygen Cylinder ValveUS$ 1 - 9MOQ: 1 Unit
-
CGA540C Wrapped Fiberglass Composite Gas Cylinder Valve CGA Cylinder Valve,Oxygen Cylinder ValveUS$ 1 - 9MOQ: 1 Unit
Brand Name
SEFIC Gas Valve Type
Place of Origin
Shanghai, China
Model Number
QF-5G Gas Valve Type
Material
Brass
Structure
Control
Standard or Nonstandard
Standard
Pressure
High Pressure
Power
Manual
Port Size
GB8335PZ27.8
Media
Gas
Temperature of Media
Medium Temperature
Gas Valve Type
1. TYPE: QF-5G
2. MEDIUM AVAILABLE: O2
3. INLET THREAD: GB8335 PZ27.8
4. OUTLET THREAD: G5/8
5. SAFETY DEVICE(Mpa):
6. WP(Mpa: 15
7.DN(mm):4
1. Specification
| Oxygen Cylinder Valve Products Series | |||||||
| TYPE | MEDIUM AVAILABLE | WP(Mpa) | INLET THREAD | OUTLET THREAD | SAFETY DEVICE(Mpa) | DN(mm) | STRUCTURAL STYLE |
| QF-2 | O2,N2 | 15 | GB8335 PZ27.8 | G5/8 | 21±1.5 | 4 | Valve type |
| QF-2B | O2,N2 | 15 | GB8335 PZ27.8 | G5/8-LH | 21±1.5 | 4 | Valve type |
| QF-2B1 | O2,N2 | 15 | G1/2 | W22×1/14 | 21±1.5 | 4 | Valve type |
| QF-2C | O2,N2 | 15 | GB8335 PZ27.8 | G5/8 | 21±1.5 | 4 | Valve type |
| QF-2D | O2,N2 | 15 | GB8335 PZ27.8 | Internal thread G5/8 | 21±1.5 | 4 | Valve type |
| QF-2E | O2,N2 | 15 | JIS B 8246 V1 φ20 | W22×1/14 | 4 | Valve type | |
| QF-2F | O2,N2 | 15 | GB8335 PZ27.8 | G5/8 | 21±1.5 | 4 | Valve type |
| QF-2G | O2,N2 | 15 | GB8335 PZ27.8 | G5/8 | 21±1.5 | 4 | Shaft type |
| QF-2M | O2,N2 | 15 | GB8335 PZ27.8 | G1/2 | 21±1.5 | 4 | Valve type |
| QF-2P | O2,N2 | 15 | GB8335 PZ27.8 | G5/8 | 21±1.5 | 4 | Valve type |
| QF-4 | O2,N2 | 15 | GB8335 PZ27.8 | G3/4 | 21±1.5 | 4 | Valve type |
| QF-5 | O2,N2 | 20 | GB8335 PZ27.8 | G5/8 | 28±2 | 4 | Valve type |
| QF-6 | O2,N2 | 15 | GB8335 PZ27.8 | Internal thread G5/8 | 4 | Valve type | |
| QF-7 | O2,N2 | 15 | GB8335 PZ27.8 | Internal thread G5/8 | 4 | Needle form | |
| QF-8 | O2,N2 | 15 | GB8335 PZ27.8 | G1/2 | 4 | Shaft type | |
| QF-12 | O2,N2 | 15 | GB8335 PZ19.2 | G5/8 | 21±1.5 | 4 | Valve type |
| QF-20 | O2,N2 | 15 | GB8335 PZ19.2 | G1/2 | 21±1.5 | 2 | Diaphragm type |
| QF-21 | O2,N2 | 15 | GB8335 PZ19.2 | W21.8×1/14 | 21±1.5 | 2 | Diaphragm type |
| QF-22 | O2,N2 | 15 | GB8335 PZ27.8 | W21.8×1/14 | 21±1.5 | 4 | Valve type |
| QF-25 | O2 | 15 | GB8335 PZ19.2 | φ7 Hose | 2 | Needle form | |
| QF-27 | O2,N2 | 15 | JIS B 8246 V1 | W22×1/14 | 21±1.5 | 3 | Valve type |
| F-1 | O2,N2 | 15 | GB8335 PZ27.8 | Internal thread W23×1/14 | 21±1.5 | 4 | Valve type |
| F-2 | O2,N2 | 15 | JIS B 8246 V2 | Internal thread W23×1/14 | 21±1.5 | 4 | Valve type |
| F-3 | O2,N2 | 15 | BS341 1×1/14 | Internal thread G5/8 | 21±1.5 | 4 | Shaft type |
| DF-4 | O2,N2 | 15 | GB8335 PZ27.8 | G5/8 | 21±1.5 | 4 | Shaft type |
2. Valve Production Process
A valve is a device that regulates, directs or controls the flow of a fluid (gases, liquids, fluidized solids, or slurries)
by opening, closing, or partially obstructing various passageways.
3. Valve Production Base
4.PACKING AND DELIVERY
5.Valve Usage / on Steel Cylinder / On Aluminum Cylinder
