Coffee Bean Peeling Machine Cocoa Bean Grinding Machine Cocoa Processing Machines

1.Description of the cocoa processing machines:

Our Taizy factory can provide semi-automatic and fully automatic cocoa bean production line, we can also configure different production line equipment according to customer's production needs.

Cocoa beans can be made into three products after roasting, peeling, grinding, oil extraction and milling: one is cocoa pulp or cocoa liquor, the other is cocoa butter, and the third is cocoa powder.

Working process of the cocoa processing machines

1)--Cocoa bean roasting machine

2)--Cocoa bean peeling machine

3)--Cocoa bean grinding machine

4)--Cocoa bean oil pressing machine

5)--Cocoa bean milling machine

6)--Cocoa powder packing machine

2.Parameter of the cocoa processing machines:

3.Features of the cocoa processing machines:

1.Multi-purpose Cocoa bean roasting machine is used for baking or drying granular materials such as peanuts, peanuts, chestnuts, walnuts, almonds, broad beans, coffee beans and melon seeds.

The cocoa bean roasting machine uses electric heating tube as the heat source, adopts the principle of rotary rolling cage, heat conduction and heat radiation, and has automatic temperature control device. The hot air is used as the drying medium, and the heat energy is applied to the baked object, which is baked during the baking process. The grilled material is continuously propelled by the propulsion device in the cage to form an uninterrupted circulation, so that the heat is evenly distributed, and the baking quality is effectively ensured.

2.The cocoa beans processed by the Cocoa bean peeling machine are evenly crushed and sorted cleanly, and the indicators meet the national standards.

The cocoa bean peeling machine is made up of peeling roller, fan and specific gravity sorting part. After feeding the beans, the beans are evenly dropped into the hopper, peeled off by the roll, and then the fan is sucked off by the wind to the machine. The dragon is stored, and the peeled cocoa beans are discharged through the material mouth. In addition, by adjusting the size of the wind and the size of the peeling gap, all the peeled skin kernels can be separated.

3.Cocoa bean grinding machine are mainly used in:  Food industry: dairy products, chocolate, bean paste, jam, peanut butter, butter drinks, etc. chemical industry: pigments, lubricants, spices, dyes, emulsified asphalt, emulsified rubber, catalysts, paints and so on.  the pharmaceutical industry: cod liver oil, confidential, Jianer cream, royal jelly, pollen and so on. daily chemicals: shoe polish, toothpaste, cosmetics, balsam, soap, detergent and so on.

The cocoa bean grinder consists of a grinding head component, a base transmission component, and a motor. Its basic working principle is shearing, grinding and high-speed agitation. Grinding relies on the relative motion of the two toothed faces, one of which rotates at a high speed and the other of which rests so that the material passing between the tooth faces is subjected to extreme shear and friction forces, while at high frequencies, high speed vortices, etc. Under the action of complex force, the material is effectively dispersed, floated, pulverized and homogenized.

4.Cocoa bean hydraulic oil press machine is mainly used for: hot pressed oil: sesame, flax, peanut, wheat germ, corn germ, etc.; cold pressed oil: pine nuts, almonds, olives, walnuts, camellia seeds, macadamia nuts, etc.; Seasonings and Chinese medicine: pepper, mustard seeds, basil, etc.

Cocoa bean hydraulic oil press is mainly composed of main body, transmission hydraulic pressure and electrical control. 1. The main body part is composed of bottom plate, column, upper slab, squeegee assembly, oil pan and nut. The oil is pushed up by the force of the cylinder assembly in the squeezing assembly, and the oil flows down from the squeezing oil sump and passes through the oil pan to the oil storage barrel. 2. Transmission hydraulic part is the main working power source of this machine to produce high oil rate. It is driven by shaft, worm gear, worm, gear pump, high pressure pump, overflow valve, manual control valve, cylinder assembly, pipe joint and other parts. composition. The electrical control part is composed of motor, voltmeter, temperature control adjustment table, pressure gauge, power insurance and other components.

5.Cocoa bean milling machine  is suitable for pharmaceutical, chemical, metallurgy, glass, food, construction and other industries. It is suitable for crushing hard and difficult materials, and it can also achieve better crushing effect on plastic and traditional Chinese medicine root materials.

6.Cocoa powder packaging machine is suitable for small bag packaging of powder materials, flour, raw meal, milk powder, soy milk powder, starch, medicine powder, condiment powder, yeast powder, coffee powder, pesticide powder, etc.

The material of the cocoa bean mill enters the pulverization bin from the hopper, and is sheared and pulverized by the movable tooth and the fixed tooth. After pulverization, the material automatically flows out from the outlet. The pulverization fineness is controlled by the screen around the toothed disc, and the fineness of the pulverization can be adjusted by changing the screen.

Our other nuts machine:

https://zztaizy.en.china.cn/

 1.peanut butter line:

1.  Are you manufacturer?

    Yes, we are. Welcome to visit our factory.
2. Can you change the machine voltage as our request?
    Yes, we can.
3.  How about your after-sales service?
   Our engineer can go outside to install and train your workers to operate the full machine line.
4.  Warranty time of your machine?
    1 year except for consumable spare parts.
5.  How about delivery time of your machine?
    Generally it needs 5-15 days for big machines or producing line,and it will be much longer but within our negotiated delivery time.
