Stainless Steel Big Corn Mill Grinder for Sale Popular Stainless Steel Spice Grinder

Stainless Steel Big Corn Mill Grinder for Sale Popular Stainless Steel Spice Grinder photo-1
Stainless Steel Big Corn Mill Grinder for Sale Popular Stainless Steel Spice Grinder photo-2
Stainless Steel Big Corn Mill Grinder for Sale Popular Stainless Steel Spice Grinder photo-3
Stainless Steel Big Corn Mill Grinder for Sale Popular Stainless Steel Spice Grinder photo-4
Stainless Steel Big Corn Mill Grinder for Sale Popular Stainless Steel Spice Grinder photo-5
Stainless Steel Big Corn Mill Grinder for Sale Popular Stainless Steel Spice Grinder photo-6
US$ 1,980 - 5,980 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
MONA
Place of Origin:
Henan, China
Model Number:
MN-20
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao ningbo shanghai
Delivery Detail:
Delivery time depends on order quantity.
Brand Name MONA
Place of Origin Henan, China
Model Number MN-20
After-sales Service Provided Engineers available to service machinery overseas

Stainless steel big corn mill grinder for sale Popular stainless steel spice grinder







introduction

Grinding mill is made of chassis, door, turbine, shaft, screen, pulleys and motors and other component parts. It adopts the stainless steel material so it has the features of wear-resistance and corrosion-resistance. The sugar grinding mill takes advantage of high-speed relative movement between movable and fixed fluted discs to grind materials. The sugar grinding mill of our company has compact structure and the crushed materials can meet national standards



Structure of herb to powder grinder

It includes main cabinet, door, turbo, spindle, screen, pulleys and motors and other component parts

Features of herb to powder grinder

1.The multifunctional stainless steel sugar grinder machine mainly  used  for  the  pharmaceutical,  chemical, food (example: ginger, chili, pepper, oil and wheat, soybean, sugar, salt, star anise, cinnamon, cocoa bean),

and other materials in the crushing process low hardness,

2.fineness adjusted between 10-120mesh,

3.high yield, fine grain size, low noise, low energy consumption, simple maintenance, and easy to install,

4.especially for oily, viscous, heat-sensitive, fibrous materials such as low hardness crushing process.

5.Whole machine made of 304 stainless steel.

working principle of herb to powder grinder

When it works, the motor drive shaft and the turbine speed rotation. Ring on the turbo and the screen broken grinding blocks, grinding vice, when the material from the hopper into the machine chamber, the material in the rotation of the turbine air flow closely friction and impact strongly on the inside of the turbine blades and vanes the gap between the blocks and grinding grinding again. In the crushed material while inhaling a lot of air turbine, which has played a cooling airflow machines, grinding materials and fine material transfer effect. Depends on the fineness of grinding material properties of the material and the mesh size, and the throughput of the material and the air.

Operation tips of herb to powder grinder



1.Carefully check each connection parts before operation.



2.Make sure the crushing chamber without hard dopant otherwise it will destroy cutters and influence machine running.



3.Change lubrication oil regularly to make sure it operates smoothly.



4.Regularly examine the wearing parts, cutter and mesh screen, change them if necessary.



5.After crushing, the residue should be cleaned and whole machine needs to be washed carefully. Cover it with a piece of tarpaulin if shored for a long time

Stainless steel big corn mill grinder for sale Popular stainless steel spice grinderStainless steel big corn mill grinder for sale Popular stainless steel spice grinder

Technical Data

Model

Production Capacity

Spindle speed

Feeding Size

Crushing Fineness

Motor Power

Overall Dimensions

weight

MN-15B

10-50kg/h

6000r/min

6mm

60-120(mesh)

2.2kw

550*400*850(mm)

100kg

MN-20B

60-150kg/h

4500r/min

6mm

40-120(mesh)

4kw

550*600*1250(mm)

280kg

MN-30B

100-300kg/h

3800r/min

6mm

40-120(mesh)

5.5kw

600*700*1450(mm)

350kg

MN-40B

160-800kg/h

3400r/min

10mm

40-120(mesh)

11kw

800*900*1550(mm)

550kg

MN-60B

300-1000kg/h

2800r/min

12mm

40-120(mesh)

18.5kw

900*900*1880(mm)

880kg

MN-80B

400-2000kg/h

2000r/min

12mm

40-120(mesh)

37kw

1100*950*1960(mm)

1500kg

MN-100B

500-3000kg/h

1500r/min

12mm

40-120(mesh)

55kw

1350*1000*2100(mm)

2500kg

Four types grinding blades used optional inside machine,according to grinding different raw materials:



SHOWS

Stainless steel big corn mill grinder for sale Popular stainless steel spice grinderStainless steel big corn mill grinder for sale Popular stainless steel spice grinderStainless steel big corn mill grinder for sale Popular stainless steel spice grinderStainless steel big corn mill grinder for sale Popular stainless steel spice grinder
