Offter FY200 Crawler Type Pneumatic Water Well Drilling Rig Impact Drilling Rig
US$ 1300 - 1500
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Huaxia Master
Place of Origin:
China
Model Number:
FY200
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
3 days
Related Products
-
FY260 Crawler Type Pneumatic Drilling Rig for Water Well 260 MetersUS$ 1300 - 1500MOQ: 1 Set -
Cheap Price FY300 Crawler Type Pneumatic Drilling Rig 300meter Water Well Drilling Rig for SaleUS$ 1300 - 1500MOQ: 1 Set
-
Cheap Price FY300 Crawler Type Pneumatic Drilling Rig 300meter Water Well Drilling Rig for SaleUS$ 1300 - 1500MOQ: 1 Set
-
Factory Direct Sale FY400 Type Crawler Water Well Drilling Rig With High EfficiencyUS$ 1300 - 1500MOQ: 1 Set
-
FY600 Crawler Pneumatic Drilling Rig 600meter Impact Drilling MachineUS$ 1300 - 1500MOQ: 1 Set
Brand Name
Huaxia Master
Place of Origin
China
Model Number
FY200
Certification
ISO
After-sales Service Provided
Engineers available to service machinery overseas
Weight
drilling rig
Dimension(L*W*H)
3800*1600*2450mm
Voltage
Diesel
Condition
New
Power(W)
65kw
CNC or Not
CNC
Drilling Speed
water well drilling rig
1. The applications of FY200 crawler pneumatic water well drilling rig
· civil engineering drilling
· geothermal drilling
· drilling with large diameter
· deep drilling footage
· fast, flexible and efficient.
2.The specifications of FY200 crawler pneumatic water well drilling rig
Model |
FY200 |
|
Gross weight |
t |
4.6 |
Dimension |
mm |
3800*1600*2450 |
Aperture |
mm |
140-325 |
Drilling depth |
m |
200 |
Feed stroke |
mm |
3000 |
Travel speed |
km/h |
2.5 |
Grade ability |
max. |
30° |
Rising height from ground |
mm |
250 |
Wind pressure |
mpa |
1.7-3.0 |
Air consumption |
m³/min |
17-35 |
Engine power |
kw |
65 |
Rotary speed |
rpm |
50-70 |
Rotation torque |
n.m |
5000-6500 |
