Home > Manufacturing & Processing Machinery > Machine Tools > Drilling Machine > Factory Direct Sale FY400 Type Crawler Water Well Drilling Rig With High Efficiency
Factory Direct Sale FY400 Type Crawler Water Well Drilling Rig With High Efficiency
US$ 1300 - 1500
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Huaxia Master
Place of Origin:
China
Model Number:
FY400
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
3 days
Related Products
-
FY600 Crawler Pneumatic Drilling Rig 600meter Impact Drilling MachineUS$ 1300 - 1500MOQ: 1 Set -
HZ-130Y Water Well Drilling Rig for Sale Hundred Well Drilling Machine Export 130 Meters Water-well RigUS$ 1300 - 1500MOQ: 1 Set
-
XYX-130 Wheel Type Hydraulic Rotary Drilling Rig Water Well Drilling Machine for SaleUS$ 1300 - 1500MOQ: 1 Set
-
XYD-130 Crawler Well Drill Machine Supply Crawler Borehole Water Well Drilling RigUS$ 1300 - 1500MOQ: 1 Set
-
HZ-200YY Hydraulic Rotary Bore Well Drilling Machine Price / Diamond Drilling Machine / Drilling Rig Water WellUS$ 1300 - 1500MOQ: 1 Set
Brand Name
Huaxia Master
Place of Origin
China
Model Number
FY400
Certification
ISO
After-sales Service Provided
Engineers available to service machinery overseas
Weight
drilling rig
Dimension(L*W*H)
5050*2100*2800mm
Voltage
Diesel
Condition
New
Power(W)
95kw
CNC or Not
CNC
Drilling Speed
water well drilling rig
1.The applications of FY400 crawler pneumatic water well drilling rig
· civil engineering drilling
· geothermal drilling
· drilling with large diameter and deep drilling footage
· It’s fast, flexible and efficient
2. The specifications of FY400 crawler pneumatic water well drilling rig
Model |
FY400 |
|
Gross weight |
T |
8.7 |
Dimension |
mm |
5050*2100*2800 |
Aperture |
mm |
140-325 |
Drilling depth |
m |
400 |
Feed stroke |
mm |
6000 |
Travel speed |
km/h |
2.5 |
Grade ability |
max. |
30° |
Rising height from ground |
mm |
250 |
Wind pressure |
mpa |
1.7-3.5 |
Air consumption |
m³/min |
17-35 |
Engine power |
kw |
95 |
Rotary speed |
rpm |
45-75 |
Rotation torque |
n.m |
8500-10000 |
