Automatic Doypack Seal Machine (insert and sealing machine)

GF1200-D  spout sealing  machine

Technique features:

Specialist in spout fitting and sealing with self-standing pouches and penguin style pouches.

Adopt PLC controller, auto-transmitting tube and bag,

accurate control, steady run, it can work all day and all night.

Transmitting bag system adopt double work station, double efficient.

Heat sealing system adopt sub-step warming, cooling design.

Sealing knife can change to fit different tube.

Withdraw bag system adopt guide rail design, it is not only withdraw bag by manual but connect with production line by guide rail to meet different requirement.

Disk structure used, less space occupied.

Touch-screen display, easy operation

Error Codes automatic alarm display.

Usage:

The machine is used to weld a plastic spout to a flexible pouch .It is suitable for packaging drinks,jelly ,soy sauce,flavorings and cosmetics (milk,face mask ) etc.

Specifications:

Capacity :20~60pcs/min

Pouch size :L×W (100-320)×(70-120) mm

Power :AC 380V, 50HZ, 3P, 5KW

Cooling Water :5L/min

Dimension :Φ2120(diam.)×1000(mm)

Control Dimension :(L×W×H)600×600×1500(mm)

Weight :1800KG
