WS Socket Clevis,power fitting,Link fitting
power fitting
Link fitting
2.product presentation
WS type socket clevis eye is used for connection with the steel foot subjected to the bottom of ball & socket-shaped insulator (ball head). According to different usage conditions & structure, socket clevis eyes are composed of single series type & double-series type.
3.Technical Parameter
National Grid Type |
Standard Type |
Size of Coupling |
Dimension (mm) |
Nominal Failure Load (kn) |
||||
C |
C1 |
C2 |
M |
H |
||||
WS-0770 |
WS-7 |
16 |
18 |
19.2 |
34.5 |
16 |
70 |
70 |
WS-1085 |
WS-10 |
16 |
20 |
19.2 |
34.5 |
18 |
85 |
100 |
WS-1290 |
16 |
20 |
19.2 |
34.5 |
22 |
90 |
120 |
|
WS-12 |
16 |
24 |
19.2 |
34.5 |
22 |
85 |
120 |
|
WS-1695 |
WS-16 |
20 |
22 |
23 |
42.5 |
24 |
95 |
160 |
WS-20 |
24 |
30 |
27.5 |
51 |
27 |
100 |
200 |
|
WS-21100 |
20 |
24 |
23 |
42.5 |
24 |
100 |
210 |
|
WS-25100 |
24 |
28 |
27.5 |
51 |
27 |
100 |
250 |
|
WS-30 |
24 |
36 |
27.5 |
51 |
36 |
110 |
300 |
|
WS-32110 |
24 |
32 |
27.5 |
51 |
30 |
110 |
320 |
|
WS-42120 |
28 |
36 |
32 |
59 |
36 |
120 |
420 |
|
Remark: we can customize various specification products based on different requirements. Meanwhile we can finish delivery of items in a shortest time.
4. Packing /shipping/ Terms of Payment
Packaging: preformed guy grip according to the concrete product cartons,wooden cases (as customer's requirements)
Delivery: usually,it will take about two weeks for the order of 10000 sets for production
Terms of Payment : By T/T
