Home > Products > mine drilling rig > KHYD125 Portable Electric Coal Mine Drilling Rig Rock Core Exploration Drilling Machine
KHYD125 Portable Electric Coal Mine Drilling Rig Rock Core Exploration Drilling Machine
- 100 Set / Sets per Month
- Qingdao
- T/T L/C D/P D/A
- 7 days
You May Like
-
XY-200 Hydraulic core drilling rig machine 200m for water well
-
BXZ-2 kohler backpack core drilling rig
-
Made in China XY-8 Hydraulic Drilling Rig for sale
-
XY-44A Hydraulic pressing machine deep water well drilling rig for sale
-
Strong Recommend Full Hydraulic XYC-3 Vehicle Type Core Drilling Rig
-
BXZ-1 Portable Backpack Core Drilling Rig Operated By One Pearson
Product Details
| Brand Name | Huaxia Master | Place of Origin | China | |
| Model Number | KHYD125 | Type | Rotary Drilling Rig | |
| Certification | ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas | |
| Warranty | 6 months | Weight | 125KG | |
| Dimension(L*W*H) | 950*460*430 MM | Power Type | Electric | |
| Voltage | 380V | Usage | Coal | |
| Condition | New | Power(W) | 7.5KW |
Product Description
1.
l Drilling rigs can be fitted with drilling rigs, and can be drilled horizontally or inclined upward or upward.
l In order to prolong the service life of the drill bit and improve the working conditions of the operator, wet drilled water can be used to discharge the powder and screw blade drills can also be used for dry draining.
l In drilling operations, we only need to operate the hand wheel, and we can advance and return quickly.
2. The specifications of KHYD125 rock drilling machine
Model | Unit | KHYD125 |
Rated output power of electric motor | kw | 7.5 |
Rated voltage of electric motor | v | 380/660 |
Rated frequency of electric motor | hz | 50 |
Rated current of electric motor | a | 15.4 |
Motor rotating speed | r/min | 1440 |
Motor phase number | three phase communication | |
Rated working mode | continuity | |
Drilling speed | mm/min | 280 |
Speed of return | m/min | |
Borehole diameter | mm | 42-80（rock stratum） |
Harness range | protodikonov`s scale of hardness | f<10 |
Maximum drilling depth | m | 25（rock stratum） |
Weight of drilling rig (excluding runways, drill pipes, drills) | kg | 125 |
Dimension(length *width *height) | mm | 950*460*430 |
