CKG1335A CNC automatic pipe thread lathe/ pipe threading machine with the factory manufacturing price
MAIN FEATURES:
1.The spindle adopts high precision spindle unit , high rotary precision, high speed, outstanding rigidity.
2.High strength base, widen the lathe bed and plate reinforcement is designed to ensure required strong cutting.
3.Machine guide adopts the precision level of preloading liner guide rail with hardness mover 58''.
4.High degree of machine modular design has good configuration option and rooting platform.
5.Optional accessories: The controller can be selected from FANUC, Mitsubishi, Siemens.
3 jaw chuck, specialized equipment tools, spring collet.
SPECIFICATIONS:
Item | Unit | Specification |
Max. swing over bed | mm | 1001 |
Max length of processing pipe diameter | mm | 1500. |
Max pipe outside diameter | mm | Electric chuck 100-350 |
Spindle bore diameter | mm | 355 |
spindle rotating speed level |
| 9 |
Spindle speed range | r/min | 6.6-200 |
Chuck form |
| Four-jaw electric chuck |
The turret from |
| Vertical four-position electric turret |
Fast moving speed X/Z | m/min | 4/6 |
Workpiece surface roughness |
| Ra,1.6 |
Turret repeat positioning accuracy | mm | 0.003 |
Tailstock sleeve stroke | mm | 250 |
Center sleeve taper |
| Morse No.6 |
Center taper |
| Morse No.6 |
Spindle center to the rail distance | mm | 500 |
Main motor power |
| 18.5kw |
Net weight | kg | 9000 |
Dimensions (length × width × height) | mm | 5800×1850×1950 |
CNC system |
| Standard configuration Beijing KND1000T, or GSK980TDc |
configurations:
Standard configuration | Select configuration |
1, CNC system: GSK980. 2, Electric turret: vertical four station electric turret. 3,3 jaw manual chuck 4, Automatic lubrication system, Cooling system,Linghten system 5,Standard tools 6,Unit packing list | 1, CNC system: Beijing KND, Japan FANUC, Germany SIEMENS. 2, Electric turret: horizontal 8 station electric turret. 3, Cradle. |
RETAILED DESCRIPTION OF LATHE MACHINE :
WE ARE LOOKING FORWARD TO COOPERATING WITH YOU
CE CERTIFICATE:
