CK30D Horizontal slant bed small cnc lathe machine desktop cnc lathe
Technical parameters
Item |
Technical parameters |
Maximum turning diameter over bed |
f 300 mm |
Maximum turning diameter over skateboard |
f 120 mm |
X-axis maximum stroke |
280 mm |
Z-axis maximum stroke |
320 mm |
Rail width |
325mm |
Spindle head model |
ISOA2-5 / MT5# |
Spindle bore |
f41mm |
Speed |
5000r/m |
Chuck |
f160 mm |
Turret type |
knife row |
Tool shank specifications |
20 mm×20 mm |
Knife block center high |
61 mm |
Main motor power |
4 kw |
X-axis motor power |
5 Nm |
Z-axis motor power |
7.5 Nm |
Foot of the bed to spindle center height |
935 mm |
Oversize |
1105×680×1194mm |
Net weight |
1000 kg |
characteristics
1. 45 º inclined bed, double linear guide rail, high accuracy, good dimensional stability;
2. The overall structure of integrated design and manufacturing foot of the bed, bed foot of the bed is made of resin sand casting, aging, u
ltra-audio frequency hardened rails for precision grinding, precision to maintain good;
3. The overall foot of the bed with high stability and rigidity, machine rigidity; fully enclosed protective structure, the machine in water, oil, dust
and safety performance is much better than similar products;
4. Tndependent spindle structure while matching precision class P4 spindle bearings, spindle speed, thermal deformation;
5. X-axis maximum stroke(280 mm), use knife row, high work efficiency.
use
This machine is suitable for high accuracy and conformance requirements for small and medium size disk parts.
slant bed small cnc lathe machine
Some of the factors that have attributed to our success and have made us the most preferred business partner are:
- State of the art manufacturing unit
- Qualified and experienced professional team
- Strong R&D
- Quality products
- Timely Execution of projects
- Competitive pricing
- Customer focused approach
f you have other questions,please tell me at any time.
welcome to our company! looking forward to your cooperations!!!
