Slant Bed CNC Lathe CK30A
Slant bed CNC lathe is designed and engineered with slant bed structure of 60 degrees. Our slant bed CNC lathe CK30A is equipped with domestic famous brand double nut preloading ball screw. The operating system of the slant bed CNC lathe can be Siemens, Guangzhou CNC or KND CNC for you choice. The slant bed CNC lathe tool can realize the clamping of complex parts such as various discs, shafts, shells, molds, etc. The slant bed CNC lathe machine is suitable for the production of multi-variety and batch products, or can process complex and high-precision parts. The slant bed CNC lathe is suitable for high-efficiency and high-precision automatic processing of small and medium-sized parts in aerospace, military and national defense, automobile, motorcycle, engineering machinery, refrigeration, and petrochemical, rolling stock and other industries.
Slant Bed CNC Lathe CK30A Specifications
| No | Project | Unit | Specifications |
|---|---|---|---|
| 1 | X-axis stroke | mm | 180 |
| 2 | Z-axis stroke | mm | 450 |
| 3 | Linear guide rail nominal width | mm | 30 |
| 4 | Spindle end | A2-4 | |
| 5 | Spindle aperture | mm | A2-6 |
| 6 | Main transmission form | mm | Φ42 (with hydraulic chuck φ30) |
| 7 | Maximum spindle speed | r/min | 4000 |
| 8 | Cutting speed | KW | 3.7 |
| 9 | Spindle speed range | mm/min | 1-4000 |
| 10 | Fast cutting speed | m/min | X20/Z:20 |
| 11 | positioning accuracy | mm | 0.008/300 |
| 12 | Dimensions | mm | 2200×1300×1700 |
| 13 | Net weight of machine tool | KG | 1850 |
Slant Bed CNC Lathe CK30A Main features
High rigidity. 60° slant bed structure, CNC machine tool consists of base, bed, vertical slide, horizontal slide, and headstock; the main basic parts are analyzed by finite element structure, reasonable structure and high rigidity.
X, Z direction feed adopts precision roller with heavy duty type lead screw with double nut preloading. The servo motor is directly connected with the lead screw through high torque and low inertia elastic coupling to ensure positioning accuracy and repeat positioning accuracy.
High rigidity. X and Z axes are supported by Taiwan’s silver linear guide rails, which greatly improve the support stiffness; the high-strength cast iron material with a nominal width of 30mm on the guide rail, resin sand molding, and sufficient secondary aging to make CNC lathe machine tool The basic parts are highly rigid and ensure the stability of CNC machine for sale for long-term use.
Slant Bed CNC Lathe CK30A Configurations
| Name | Place of origin | Brand | Remarks |
|---|---|---|---|
| CNC system and each shaft drive motor | Guangzhou | GSK | GSK980TC3 |
| Spindle | Anyang | Continued flight | 4000rpm |
| Linear Guides | Taiwan | Shangyin / Yintai | Nominal diameter 30mm |
| Knife tower | Changzhou | HTC | 8-station electric |
| Two-axis ball screw | Jiangsu | Start up | Double nut preload |
| Two-axis angular contact ball bearing | Harbin | Harbin | 7205 group |
| Two-axis coupling | Domestic | Wuxi Coret | Flexible coupling |
| Centralized automatic lubrication system | Domestic | Ding | 2232X |
| Hydraulic chuck / rotary cylinder (optional) | Taiwan | Jiahe | 6-Inches |
| Cooling device | Dongguan | Boateng Machinery | MC-4000/ACP-251A |
| Lighting system | Domestic | Sanying | LED |
| Communication Interface | Domestic | System manufacturer | RS232 |
| TOOL | Domestic | Market purchase | One set of hex wrenches, one open end wrench, one word and one Phillips screwdriver |
| Horizontal adjustment block | Domestic | Market purchase | Earthquake resistance |
| technical manual | Domestic | Market purchase | Instruction manual, certificate, packing list, system operation and programming manual, drive manual, inverter manual |
Slant Bed CNC Lathe CK30A standard exported wooden case
As the professional CNC machine designer and manufacturer, Taian HAISHU Machinery Co., Ltd (Haishu Machinery) is the high-tech enterprise specialized in CNC machine development, production, sales and service since 2001. Our high quality and innovative products include CNC lathe, CNC milling machine, CNC machining center, CNC turn-mill machine, CNC tool grinding machine, CNC pipe threading lathe, CNC wood lathe, stone CNC machine, CNC root canal file grinder and custom CNC equipment for special requirements.
HAISHU Machinery is not only manufacturing best quality CNC machine products but also providing custom product design and after sale services. Welcome to contact us for detailed information.
