cnc450B-1 cnc lathe /new lathe /new cnc lathe machine/mini lathe Price
Technical paramete
CNC450(B-1)slant bed CNC lathe
(3-axis harden guide, three gears change speed, harden cutting )
|
No. |
Item |
Unit |
specifications |
CNC450(B-1) | |||
1 |
Max.rotation diameter on lathe’ body |
mm |
450 |
2 |
piece lengt |
mm |
750 |
3 |
Max.turning diameter |
mm |
400 |
4 |
Spindle nose type and code |
mm |
A8 |
5 |
Hydraulic chuck |
mm |
φ250 (10") |
6 |
Front spindle bore taper |
|
1:20 |
7 |
spindle bore |
mm |
60 |
8 |
Spindle form |
Programmable three gears auto hydraulic speed change |
|
9 |
Spindle frequency control speed range |
rpm |
20-3000 |
10 |
X/Z Rapid traverse |
mm/min |
20000 |
11 |
Main servo motor power |
kW |
11 |
12 |
X/Z-axis motor max.torque |
N.m |
10 |
13 |
Power specifications |
V |
380±10%. 50Hz±1Hz |
14 |
Turret transfer time (one station) |
s |
1.6(horizontal12) |
15 |
Turret transfer repeat positioning accuracy |
|
0.005" |
16 |
X-axis travel |
mm |
300 |
17 |
Z-axis travel |
mm |
1100/1350/1850 |
18 |
B-axis travel |
mm |
1100/1350/1850 |
19 |
Hydraulic turret form |
|
Horizontal 12 hydraulic turret |
20 |
Tailstock sleeve diameter/ travel |
mm |
70/100 |
21 |
Tailstock tapered bore taper |
Morse |
4# |
22 |
Tailstock form (programming optional) |
|
Electric drive |
23 |
Tailstock sleeve form |
|
Hydraulic drive |
24 |
Knife handle size |
mm |
25×25 |
25 |
Net weight |
kg |
5000 |
26 |
Size(L×W×H) |
mm |
3000×1650×1900 |
Standard configurations:
1.GSK980TDc controllers sytem
2.Spindle 3 gears frequency control speed
3.Hydraulic solid chuck
4.Horizontal 12 hydraulic turret
5.Three axis harden guide
6.Electric tailstock,hydraulic sleeve
7.Turning coolant system
8.Auto lubrication system
9.Whole protection door
Optional configurations:
1.fanuc/siemens controller system
2.Hydraulic hollow chuck
3.Electric and programming tailstock
4.Auto bar feeder
5.Auto chip cleaner
6.Auto catcher device
7.Auto protection door
8.Loading robot
