Machine Grinder Model MY1224 for Precision Grinding
US$ 4,600 - 4,950
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
WMT
Place of Origin:
Anhui, China
Model Number:
MY1224
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Machine Grinder MY1230 With Precision Metal GrindingUS$ 5,600 - 5,800MOQ: 1 Set -
High Precision Surface Grinding Machine MY1022 With CE StandardUS$ 3,695 - 3,700MOQ: 1 Set
-
MY1022 Hydraulic Surface Grinding MachineUS$ 3,650 - 3,750MOQ: 1
-
Machine Grinder MY1224 for Precision Metal GrindingUS$ 5,430 - 5,550MOQ: 1 Set
-
M820 Manual Surface Grinding Machine for Metal Work With CEUS$ 2,390 - 2,490MOQ: 1
Brand Name
WMT
Place of Origin
Anhui, China
Model Number
MY1224
Type
Surface Grinding Machine
Certification
CE certificate
After-sales Service Provided
Engineers available to service machinery overseas
Weight
1650kgs
Dimension(L*W*H)
1960x1630x1870mm
Voltage
customer appoint
Condition
New
Power(W)
1.5kw
CNC or Not
Normal
Features:
Machine grinder
Surface grinding machine for metal
Processing stability is very high
Good performance
CE
Hydraulic surface grinding machine with magnetic chuck MY1224
| Item | Specification | MY1224 | MY1230 | |
| Worktable | piece to be ground(LxWxH) | 600x300mm | 700x320mm | |
| Max.travel of table(LxW) | 640x320mm | 640x370mm | ||
| Table max. cutting area(Lxw) | 640x320mm | 760x370mm | ||
| Number of T-slot | 1x14mm | 1x14mm | ||
| The grinding head | Distance from table surface to spindle center | 490mm | 540mm | |
| Wheel size(dia x width x bore) | 250x25.4x76.2mm | 335x40x127mm | ||
| Spindle speeds | 1440r/m | 1440r/m | ||
| The amount of feed | Table longitudinal (left and right) speed(stepless) | 3-20/min | 5-25/min | |
| Table horizontal(before and after)the amount of feed | Continous(variable speed) | 150mm/min | 150mm/min | |
| Intermittent(stepless) | 0-5 | 0-5 | ||
| The handwheel rotates | 4mm | 4mm | ||
| Handwheel each grid | 0.02mm | 0.02mm | ||
| Vertical (up and down)feed wheel feed | The handwheel rotates | 2mm | 2mm | |
| Handwheel each grid | 0.01mm | 0.01mm | ||
| Motor | Spindle motor | 2.2mm | 4mm | |
| Cooling motor | 40kw | 40kw | ||
| Reversing feeder | Hydraulic motor | 1.5kw | 1.5kw | |
| Working pressure | 3mpa | 3mpa | ||
| Fuel tank capacity | 80L | 80L | ||
| The max.flow | 18L/min | 18L/min | ||
| Working precision | The machined surface of the base of parallelism | 300/0.004mm | 300/0.004mm | |
| Surface Roughness | Ra0.32um | Ra0.32um | ||
| Net weight | 1.5T | 2.1T | ||
| Gross weight | 1.65T | 2.35T | ||
| Machine size | 1960x1630x1870mm | 25600x2430x1920mm | ||
Machine details:
