High Speed Bt40 Belt Driven Spindle for Cnc Machine Centre
Feature:
Belt type BT40-140
1. Spindle speed: 10000 rpm;
2. Spindle with oil cooling, effective maintenance of the spindle temperature stability;
3. Good labyrinth ring design, effectively prevent cutting oil and exclude foreign materials.
4. Optional :center outlet device;
5. This spindle can be used for process components and mold engraving;
6. The spindle has a reserved floating buckle device.
Specification
|
Model |
SP40-140 |
|
Spindle speed |
10000 RPM |
|
Balance level |
G1 |
|
Nasal end deflection |
0.003mm |
|
Inner holder deflection |
0.002mm |
|
Normal temperature rise |
+18° |
|
Drive belt size |
5GT-48T |
|
Broaching tool |
four petals |
|
Installation |
vertical |
About us:
Dongguan Mihong Mechanical Hardware Co., Ltd is a professional manufacturer and supplier of high-precision cnc rotary table, cnc tool holder, cnc machine spindle and cnc machine center .
The precision machinery and professional talent,superb,sophisticated technology,has won the praise of China machine tool industry.
The main products:
1. Cnc rotary table :4th axis nc rotary table ,cam rotary table ,motor drive rotary table,5th axis rotary table etc.
2. Cnc machine spindle:
SP30 belt drive spindle ,SP40 belt drive spindle,SP50 belt drive spindle;
ST40 direct drive spindle ,ST50 direct drive spindle ;
ST30 tapping & drilling machine;
cnc lathe machine spindle : A2-4,A2-5 and A2-6
3.Cnc machine center :VMC550/VMC650/VMC850/VMC1160 etc.
4. Tool holder series, CNC tool holder, CNC tool holder, collet chuck, high speed tool-holder, machine
tool holder, chuck, Powerful toolholder, CNC toolholder, ER toolholderis divided into BT toolholder, NT
toolholder, MT toolholder, etc.,
Company view
Customer cases
Our service:
1. OEM Manufacturing
2. Sample order
3. Cnc machine center solution.
4. Short lead time
Contact information
More information to company, copy the official website link for reference.
ATTN: Deanna
Add:No 8 Xingsan Road ,Chenwu Wusha, Changan Town ,Dongguan City ,Guangdong Province ,China
Tel:+86-769-85071566
Web: /
