Small CNC Lathe Machine Specification for Sale Low Price From China Factory CK6132
US$ 7,000 - 9,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Lu Young
Place of Origin:
Shandong, China
Model Number:
CK6132A
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CK6130 CNC Horizontal Lathe With Numerical ControlUS$ 7,000 - 9,000MOQ: 1 Set -
CK0640 High Precision Horizontal CNC Mini Lathe for Metal With CE, ISOUS$ 4,500 - 6,500MOQ: 1 Set
-
CK6432 China Small Metal Used Cnc Lathe Machine for SaleUS$ 5,800 - 9,000MOQ: 1 Set
-
CK6140 Small Flat Bed Used Cnc Lathe Machine Price With ISO,CEUS$ 8,000 - 10,000MOQ: 1 Set
-
CK6136 High Precision Horizontal Small Torno Mechanic Cnc Machine PriceUS$ 7,200 - 9,000MOQ: 1 Set
Brand Name
Lu Young
Place of Origin
Shandong, China
Model Number
CK6132A
After-sales Service Provided
Engineers available to service machinery overseas
Condition
New
Small CNC Lathe Machine Specification for Sale Low Price From China Factory CK6132
Product Description
| Flat Bed Small CNC Lathe Machine CK6132 | |
| Item | CK6132 |
| Max. swing dia. over bed | 360mm |
| Max. swing dia. over cross slide | 150mm |
| Max. processing length | 450mm |
| Dia. of spindle hole | 42mm |
| Through hole dia. of drawing pipe | 31mm |
| Spindle speed | 50-2500mm |
| Tool holder | 4 station electric tool post(optional 6/8staion electric turret) |
| Tool bar section | 20X20 mm |
| Main motor power | 4kw |
| X/Z axis travel stoke(mm) | 260/450 |
| X/Z axis fast feeding speed | 6/8m/min |
| X/Z axis position accuracy(mm) | 0.01/0.015 |
| X/Z-axis repeatability(mm) | 0.012/0.013 |
| Clamping | 3 jaw manual chuck |
| Tailstock sleeve dia. | 60mm |
| Tailstock sleeve travel | 100mm |
| Tailstock taper | MT4 |
| Dimension | 1820x1100x1550 |
| weight | 1200kg |
| CK6132 | |
| Standard configuration: | Optinal configuration: |
| GSK928 CNC Controller | Siemens,Fanuc cnc controller system |
| Servo motor for X,Z axis, Servo driven | pneumatic chuck,hydraulic chuck |
| 3 Jaw Manual Chuck | pneumatic tailstock,hydraulic tailstock |
| 4 station electric tool post | 6 staion tool turret,8staiton tool turret |
| Auto lubrication system | Auto feeder system |
| lighting system | Chip conveyor |
| cooling system | |
|
|
|
