50mm radial drill machine
- 10 Set / Sets per Month
- Qingdao
- T/T Credit Card
- Radial Drilling Machine Z3040X13
- M12 The New Product articulated arm tapping machine
- M12 The New Product tap hole drilling machine
- China Z3032 Z3040 Z3050x16 Z3063 Z3080 Z30100 Heavy duty hydraulic metal arm radial drilling machine price for sale
- Best Export Model ZQ3050 radial drilling machine price
- LT-160J Bench drilling machine
Product Details
Brand Name: | STEEL HORSE | Place of Origin: | Shandong, China | Model Number: | ZQ3050 |
Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas | Weight: | 3500 |
Dimension(L*W*H): | 2500*1060*2800 MM | Voltage: | 220-450V | Condition: | New |
Power(W): | 4KW | CNC or Not: | CNC | Drilling Speed: | 25-2000 |
Product Description
50mm radial drill machine
1. Features:
This machine is suitable for drilling mainframe pieces,Stability,Hydraulic clamping,suitable for mass production,flow process,Faster,Save time and effort.
Mechanical transmission,
Machanical clamping,
Mechanical speed,
Automatic take-off and landing,
Automatic feed,
Double Column.
2.Specification:
Main date | ZQ3050×13 | ZQ3050×16 |
Max.drilling dia mm | (steel)32 (cast iron)40 | (steel)32 (cast iron)40 |
Distance from spindle nose to table surface mm | 260-1150 | 260-1150 |
Distance between spindle asix and column surface mm | 360-1600 | 360-1600 |
Spindle travel mm | 200 | 200 |
Spindle Cone (Morse) | 5 | 5 |
Spindle speed step | 6 | 6 |
Spindle feeding step | 6 | 6 |
Spindle feeding step mm/r | 0.10-0.56 | 0.10-0.565 |
Spindle speeds range r/min | 78/135/240/350/590/1100 | 78/135/240/350/590/1100 |
Main motor power kw | 4 | 4 |
Machine shape dimension mm | 1950×810×2450 | 2170×950×2450 |
Weight KG | 2400 | 2800 |
3.Details photo:
4.Radial Drilling Machine export to world wide:
Madin in China,Design in China.
