Z3040X13 Radial Drilling Machine
1.Z3040X13 Radial Drilling Machine specification:
Mechanical transmission
Mechanical clamping
Mechanical speed
Automatic take-off and landing
Automatic feed
Double Colum
Description |
Z3032×10/1 |
Z3040×12/1 |
Z3050×16/1 |
Z3063×20/1 |
Z3080×25 |
|
Max |
32mm |
40mm |
50mm |
63mm |
80mm |
|
Distance between spindle axis and column |
Max |
1000mm |
1600mm |
1600mm |
2000mm |
2500mm |
Min |
300mm |
350mm |
350mm |
450mm |
500mm |
|
Distance spindle |
Max |
1000mm |
1250mm |
1220mm |
1600mm |
2000mm |
Min |
220mm |
350mm |
320mm |
400mm |
550mm |
|
Spindle travel |
280mm |
315mm |
315mm |
400mm |
450mm |
|
Spindle taper |
4# |
4# |
5# |
5# |
6# |
|
Range of spindle speeds |
32-2500 |
25-2000 |
25-2000 |
25-1600 |
16-1250 |
|
Number of spindle speeds |
16 |
16 |
16 |
16 |
16 |
|
Range of spindle feeds |
0.10-1.25 |
0.04-3.20 |
0.04-3.20 |
0.04-3.20 |
0.04-3.20 |
|
Number of spindle feeds |
8 |
16 |
16 |
16 |
16 |
|
Table size |
600×450 |
500×630 |
500×630 |
630×800 |
800× |
|
Travel of spindle head |
|
900mm |
1250mm |
1550mm |
2000mm |
|
Power of main motor |
2.2kW |
3kW |
4kW |
5.5kW |
7.5kW |
|
Net weight |
1600kg |
3000kg |
3500kg |
7000kg |
11000kg |
|
Overall |
1760X800X2050mm |
2150×1070 |
2500×1070 |
3080×1250 |
3730×1400 |
|
| Item | Qty |
| Radial drilling machine | 1 set |
| withdrawl wedge | 1 piece |
| reduction sleeve | 1 piece |
| drill chuck | 1 piece |
| table | 1 piece |
| connecting rod | 1 piece |
| English operation manual | 1 set |
Steel horse,Quality first,Faith forever.
