QK1350 cnc pipe threading lathe machine
the surface of the slide rail of the bed is treated by the super audio quench, which can be endurable and wear-resisting. the slide rail f saddle is treated by wear-resisting layer coated, to avoid the crawling.
There are two types of speed change: Manual and step less.
Set up self lubrication system, and easy to maintain.
Item |
Unit |
Parameter |
Parameter |
Parameter |
Parameter |
Max. swing diameter over bed |
mm |
1200 |
1200 |
1200 |
1200 |
Max. swing diameter over carriage |
mm |
710 |
710 |
710 |
710 |
Spindle bore diameter |
mm |
520 |
520 |
520 |
520 |
Pipes to be machined |
mm |
330~510 |
330~510 |
330~510 |
330~510 |
Spindle speed |
rpm |
8~190/3 shifts |
8~190/3 shifts |
8~190/3 shifts |
8~190/3 shifts |
Center distance |
mm |
1000 |
1500 |
2000 |
3000 |
Max. cross travel |
mm |
500 |
500 |
500 |
500 |
Max. longitudinal travel |
mm |
750 |
1250 |
1750 |
2750 |
Rapid feed rate |
mm/min |
4000 |
4000 |
4000 |
4000 |
Chuck size |
mm |
1000 |
1000 |
1000 |
1000 |
Main motor power |
kW |
22 |
22 |
22 |
22 |
Machine size |
mm |
4500×2200 ×2200 |
5000×2200 ×2200 |
5500×2200 ×2200 |
6000×2200 ×2200 |
Machine weight |
kgs |
14500 |
15000 |
16000 |
17000 |
No |
Item |
Remark |
1 |
4-jaw chuck |
2 sets |
2 |
Morse dead center |
1 pc |
3 |
Sizing block |
6 pcs |
4 |
Chuck wrench |
1 pc |
5 |
Tool post wrench |
1 pc |
6 |
Open-end wrench |
1pc/each |
7 |
Hex key wrench |
1pc/each |
8 |
Foundation bolts |
6 pcs |
9 |
Compact disk |
1 pc |
10 |
Communication wire |
1 pc |
11 |
Lighting system |
yes |
12 |
Cooling system |
yes |
13 |
Hand - held electronic pulse wheel |
yes |
14 |
CNC manual |
1 set |
15 |
Instruction manual |
1 set |
16 |
Certificate of conformity |
1 set |
17 |
Packing list |
1 set |
Pls send inquiry to me for optioanl accessories and other further information about such cnc pipe threding lathe machines.
