Saw Machine CS-225 CS-250 CS-275 Circular Saw Metal Cutting
The main performance characteristics:
1. The HSS saw blade of our circular saw is highly efficient and durable,
2. The 24V low-voltage controlled hand switch is convenient for operation,
3. The double clamp structure can quickly clamp materials and rotate 45°from side to side for cutting;
4. Our circular saw features a double speed motor and with low noise can slow down through worm and gear;
5. The safety hood of saw blade opens or closes according to the cutting needs, making it safety;
6. The cooling system of circular saw can prolong the service life of saw blade and improve the precision of the work piece;
7. Vice complete with anti-burr device, Movable head 45°right and left;
8. Reduction unit in oil bath, Membrane pump for coolant.,
Application:
For high precision metal cutting, is the ideal equipment for the industrial and mining enterprises and small workshops, use is very extensive.
Product main technical parameters:
Model |
CS-225 |
CS-250 |
CS-275 |
|
Max. blade size |
225mm(8.9″) |
250mm(9.8″) |
275mm(10.8″) |
|
Machining capacity |
Round steel@90° |
60mm(2.36″) |
60mm(2.36″) |
70mm(2.75″) |
Square steel@90° |
50×50mm(2″×2″) |
75×45mm(3″×1.77″) |
90×45mm(3.5″×1.77″) |
|
Round steel@45° |
52mm(2.05″) |
55mm(2.16″) |
65mm(2.56″) |
|
Square steel@45° |
50×50mm(2″×2″) |
50×50mm(2.16″×1.77″) |
75×45mm(2.75″×1.77″) |
|
Blade speed @ 50HZ |
46rpm |
42rpm |
42rpm |
|
Vice opening |
70mm(2.8”) |
100mm(2.8”) |
100mm(4”) |
|
Motor power |
750W(1HP) |
1.1KW(1.5HP) |
1.1KW(1.5HP) |
|
Drive |
Gear |
Gear |
Gear |
|
Package size |
64×39×72cm |
89×58×78cm(body) 77x46x33cm(stand) |
89×58×74cm(body) 77x46x33cm(stand) |
|
NW/GW |
63/75kg |
143/171kg |
148/174kg |
|
Tengzhou Luzhong Machine Tool Co., Ltd. is a large-scale manufacturing enterprisewith glorious chievement and long history .Founed in 1992 ,company covers an area of 30 thousand square meters, the construction covers area of 250 thousand square meters.
Our main products are : CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machine ,Drilling Machine ,Milling Machine and others metal cutting machine tools .All the products above have passed CE ,ISO ,SGS ,TUV certificates .
"THE BEST QUALITY ,CREATED BY LUZHONG"
All of our machines are subject to strict quality control.Especially in the production process.
The Machines like lathe machine , cnc lathe machine ,cnc milling machine , cnc turning center ,Radial drilling machines, drilling milling machines ... ... have production lines as below:
1.High strength Casting making .
2.Processing production.
3.High precision quenching process.
4.Assembling process.
5.Spray paint process.
6.And also the finished product come out .
Our Company Tengzhou Luzhong Machine Tool Co.,Ltd has the certifications as :CE ,ISO ,SGS ,TUV ,SONCAP certificates and on on .
In the past years , we joint the machine exhibition every year .We have experiences in servicing customers for over 20 years .
1.Why choose us ?
We are a cnc machine manufacturer can provide the high quality, competitive price and good after-sale service.
We have our own technical team, can provide the customized solutions according to your request( your workpieces ,Your drawings and so on)
We go the full 24-hour performance and accuracy test before shipment.
2.What machines can be available in your factory?
We have co many kinds machines like :Lathe Machines. CNC Lathe Machines. Milling Machines.CNC Milling Machines.CNC Machining Center , Drilling Machines ,Slotting Machines and sawing machines and so on .
3.What certifications you have ?
We have certifications like:CE certifications
CO certifications
ISO certifications and also CIQ certifications and so on .
4.What payment terms you can accept?
Mostly using TT.
But LC also available
5.What services you can offer ?
Warranty for one year .
English manual and video for machine using and maintenance.
OEM,ODM is available in our factory.
24 hours online technical service
Engineers available to service machinery overseas
Free customers training in our plant.
