BS-280G Metal Cutting Band Sawing Machine with CE Certificate
The main features :
1. The European design band saw features European design, dovetail-type clamp movement and locking mechanism.
2. The European design band saw features double-speed selection.
3. The saw bow can be rotated from 0 to 45 . It has the characteristics of worm gear box transmission structure.
4. The calibration of the jaw is convenient for adjustment and positioning at any angle.
5. The falling speed of saw bow is controlled by hydraulic cylinder.
6. The European design band saw has a sizing device (the machine will automatically stop after sawing the materials).
7. The European design band saw has a power break protection device (the machine will automatically power off when the rear protective cover is opened).
8. The cooling system of the European design band saw can prolong the service life of saw blade and improve the precision of the workpiece.
9. It is equipped with a block feeder (with fixed sawing length).
Product main technical specifications:
Model |
BS-280G |
|
Capacity |
Circular @90° |
220mm(8.6”) |
Rectangular @90° |
250*155mm(10”*6.1”) |
|
Circular @60° |
100mm(4'') |
|
Rectangular @60° |
80x95mm(3.1''x3.7'') |
|
Circular @45° |
160mm(6”) |
|
Rectangular @45° |
160*110mm(6.3”*4.3”) |
|
Blade speed |
@50Hz |
40/80MPM |
Blade size |
27*0.9*2450mm |
|
Motor power |
0.75/1.1kw /1.5HP(3PH) |
|
Drive |
Gear |
|
Packing size |
133*80*105cm(body) 67*40*62cm(stand) |
|
N.W./G.W. |
254/287kg |
|
|
|
| BS-712N Band Sawing Machine | GH4235 Band Sawing Machine |
|
|
| BS-280G Band Sawing Machine | GHS4250 CNC Band Sawing Machine |
Tengzhou Luzhong Machine Tool Co., Ltd. is a large-scale manufacturing enterprise with glorious chievement and long history .Founed in 1992 ,company covers an area of 30 thousand square meters, the construction covers area of 250 thousand square meters.
Our main products are : CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machine ,Drilling Machine ,Milling Machine and others metal cutting machine tools .All the products above have passed CE ,ISO ,SGS ,TUV certificates .
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
Whatsapp :+86 15063206860
Skype:luzhongsara
Web:
