GH4220 GH4228B GH4230 Band Saw Machine Horizontal Band Saw
The main performance characteristics:
1.Saw frame travels across solid dual-column guides
2.Rigid, adjustable saw blade guides prevent lateral escape of the saw blade and ensure maximum angular accuracy
3.Ideally positioned control panel within comfortable reach on top of the saw frame
4.At the end of each sawing cycle, the saw blade frame will automatically return to the home position
5.Tthrottle valve allows infinitely variable saw frame feed
6.Two cutting speeds for a wide spectrum of materials and workpiece diameters
7.Manually adjustable workpiece clamping and linear stop
8.Coolant system
Application:
For high precision metal cutting, is the ideal equipment for the industrial and mining enterprises and small workshops, use is very extensive.
Product main technical parameters:
Main technical parameters |
GH4220 |
GH4228B |
GH4230 |
Sawing range |
200-200×200mm |
280-280×280mm |
300-300×300mm |
Belt saw blade size |
2650×27×0.9mm |
3505×34×0.9mm |
3505×34×1.1mm |
Saw blade speed |
27,45,69mm/min |
27,45,69mm/min |
27,45,69mm/min |
Working clamping mode |
Manual |
hydraulic pressure |
hydraulic pressure |
Main motor power |
1.5kW |
3kW |
3kW |
Hydraulic motor power |
0.55kW |
0.75kW |
0.75kW |
Cooling pump power |
0.04kW |
0.04kW |
0.04kW |
External form size |
1300×800×1100mm |
1860×2400×1400mm |
1860×900×1400mm |
|
|
| BS-712N Band Sawing Machine | GH4235 Band Sawing Machine |
|
|
| BS-280G Band Sawing Machine | GHS4250 CNC Band Sawing Machine |
Tengzhou Luzhong Machine Tool Co., Ltd. is a large-scale manufacturing enterprise with glorious chievement and long history .Founed in 1992 ,company covers an area of 30 thousand square meters, the construction covers area of 250 thousand square meters.
Our main products are : CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machine ,Drilling Machine ,Milling Machine and others metal cutting machine tools .All the products above have passed CE ,ISO ,SGS ,TUV certificates .
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
