Home > Manufacturing & Processing Machinery > Machine Tools > Drilling Machine > Chinese Radial Manual Drilling Machine Price Z3050
Chinese Radial Manual Drilling Machine Price Z3050
US$ 6,000 - 10,000
MOQ: 1 set
Key Specifications
Get Latest Price
Brand Name:
HIENCE
Place of Origin:
Shandong, China
Model Number:
Z3050
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Industrial Drill Press Hydraulic Radial Drilling Machine Z3050US$ 6,000 - 10,000MOQ: 1 -
Chinese Radial Manual Drilling Machine Price ZQ3040US$ 2,000 - 4,000MOQ: 1
-
China Excellent Quality Big Diameter Radial Drilling Machine Price ZQ3040US$ 2,000 - 4,000MOQ: 1
-
ZX7550CW Radial Drilling Machine WorkingUS$ 2,300 - 2,800MOQ: 1 Set
-
Radial Drilling Machine,latest Technology ZQ3040US$ 2,000 - 4,000MOQ: 1 Set
Brand Name
HIENCE
Place of Origin
Shandong, China
Model Number
Z3050
Certification
CE Standard
After-sales Service Provided
Overseas service center available
Weight
3500kg
Dimension(L*W*H)
2500*1060*2800mm
Voltage
380V
Condition
New
Power(W)
4kw
CNC or Not
Normal
Drilling Speed
25-2000rpm
Chinese radial manual drilling machine price Z3050
Product Description
1.specifications
Iterms |
Specifications |
Max drilling diamater |
50mm |
|
The gap between the center line of the spindle and riser bus bar |
Max:1600 mm Min 350mm |
|
The gap between the spindle end and the working face of pedestal |
Max 1220mm Min 320mm |
Travel of spindle |
300 mm |
Taper of spindle |
5# |
Range of spindle speed |
25-2000 rpm |
Number of spindle speeds |
16 |
Range of spindle feeds |
0.04-3.20 mm/r |
Table size |
500*630mm |
Horizontal trave of spindle head |
1250 mm |
Motor power |
4 KW |
Weight |
3500 kg |
Overall dimensions |
2500*1060*2800mm |
Reference pictures
