Garden Farming 40-55hp tractor with 4 in 1 bucket
- 300 Unit / Units per Month
- Qingdao port
- T/T Credit Card
You May Like
Product Details
Brand Name | MAP | Size | 3835*1620-*2815 | |
Condition | New | Transmission Type | Manual | |
Gross Vehicle Weight | 1734 kg | Fuel Type | Diesel | |
Emission Standard | Euro 1 | Drive Wheel | 4x4 | |
Engine Capacity | 4 - 6L |
Product Description
Garden Farming 40-55hp tractor with 4 in 1 bucket
*4*4 wheel drive
*Dual clutch
*Cabin with warmer or canopy with ROPS
Qualifications
ISO9001 CERTIFICATION,BV ASSESTMENT
Specification
Model | 504 |
Type | 4WD Wheeled Type |
Length(to the front ballast) | 3835mm |
Width | 1620mm |
Height (to the exhaust vent) | 2135mm |
Front Wheel Tread | 1280mm |
Rear Wheel Tread | 1300 Fixed or 1200-1500 Adjusted |
Axle Base | 2030mm |
Min. Ground Clearance | 325mm |
Structure weight | 1734kgs |
Front ballast weight | 168kgs |
Rear ballast weight | 300kgs |
Rated traction force | 1150kgs |
Engine Model | 498 |
Engine Type | 4-Cylinder |
Cooler type | Water |
Stroke | 4 Stroke |
Rated Power | 50hp |
Rated Speed | 2400r/min |
Fuel | Diesel |
Front Wheel Tyre | 8.3-20 |
Rear Wheel Tyre | 12.4-28 |
Clutch | Dual-stage clutch |
Steering | Power steering |
Transmission Type | 8+4 or 8+8 with shuttle gearshift or (8+4)×2 with creeper shift |
Suspension Type | 3-point links |
Type and Rev | Semi-independent Type 540/1000 |
Spline Size | F35 Rectangle Spline with 6 teeth |
conveyance/Shipment qty
QTY/20 FCL :onePCS
QTY/40 FCL:3PCS
Weifang Map Power co.,Ltd.
Tel:86-536-8502890
Fax:86-536-8502136
