Backhoe Loader
*Chinese name " both ends is busy " . the front is loaded device, back to digging.
* you only need to rotate the seat to change the role from loader to the excavator.
*Applications: Backhoe Loaders are mainly used for urban and rural road construction and maintenance, cable casting ,
power and airport projects, municipal construction, water conservancy construction, rural housing construction.etc
Cab
Cab can be replaced independently, it connects with excavator frame by four damping devices, backhoe side turned to the
big window structure is conducive to broadening their horizons and ventilation.
Working device:
Load-side adopts a unique eight-bar linkage that automatically keep the bucket level when the loading arm lift bucket to keep
the original angle, to ensure that the material will not be spilled. According to need, you can also add some attachments,
such as a multi-bucket, fork, log grappler and so on.
Travel System:
Travel System adopts hydrostatic drive. Using German technology shift driven front axle.
Hydraulic System:
Main pump adopts Germany Rexroth pump technology, Chinese wellknown enterprises produce the pump. All excavators
adopts open hydraulic system, with good micro performance, and make the operation much stabler, easier, more responsive,
more accurate tap control, to maximize power and improve fuel efficiency.
Power system
The engine adopts the YTO Group Corporation and RICARDO designed classic model - LR4105ZG96, maximum output
power is 65KW
According to the needs of users, Cummins engine is optional, B3.3T-C80, power is 60 kw. You may also choose Yanma,
Perkins engine and so on.
Item |
Unit |
Parameter |
|
Total Length |
mm |
5100 |
|
Total Height |
mm |
2900 |
|
Total Width |
mm |
1960 |
|
Total Operating Weight |
kg |
4900 |
|
Backhoe Parameter |
Rated Backhoe Bucket Capacity |
m3 |
0.3 |
Max. Digging Depth |
mm |
3400 |
|
Max. Digging Height |
mm |
5000 |
|
Max. Digging Radius |
mm |
4600 |
|
Turning Angle of Movable Arm |
° |
180 |
|
Loading Parameter |
Rise Height |
mm |
3700 |
Discharge Height |
mm |
2700 |
|
Min. Turning Radius |
mm |
4800 |
|
Discharge Distance |
mm |
1000 |
|
Rated Loading Weight |
kg |
1600 |
|
Rise Time of Movable Arm |
s |
3.5 |
|
Fall Time of Movable Arm |
s |
2.5 |
|
Comprehensive Time |
s |
7 |
|
Engine Model |
YUNNEI 490T |
||
Rated Power of Engine |
KW |
42 |
|
Engine Flux |
ml/r |
40 |
|
Work Pressure |
Mpa |
16~18 |
|
Max. Grade Ability |
% |
25 |
|
Walking Speed |
km/h |
18~28 |
|
Min. Ground Clearance |
mm |
260 |
|
Wheel Base |
mm |
2000 |
|
Tread |
mm |
1530 |
|
Tire model |
mm |
20.5-16 |
|
