Home > Products > Backhoe loader > Muti-function backhoe loader 30-25 construction machine
Muti-function backhoe loader 30-25 construction machine
- 100 Unit / Units per Month
- Qingdao
- T/T Credit Card
- China construction use WZ30-25 cheap backhoe loader
- China factory hydraulic WZ30-25 small backhoe loader
- Cheap mini small backhoe loader for sale
- Hot sale WZ30-25 mini tractor backhoe loader wirh cheapest price
- hydraulic backhoe loader, mini backhoe loader
- WZ30-25 top quality and pilot control loader back excavator , four drive backactor loader
Product Details
Brand Name: | MAP | Place of Origin: | Shandong, China | Type: | Backhoe Loader |
Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas | Warranty: | 12months |
Condition: | New | Dimension(Long * Breadth * High): | 8720*2170*2950mm | Moving Type: | Wheel Loader |
Rated Load: | 4000KG |
Product Description
Weifang Map Power Co., Ltd., was founded in 2006. We are a professional manufacture and chain supplier specializing in construction machinery and agricultural equipments.70% of our products are made for export. We keep diverse products according to customer and market demand. We produce and supply site dumpers, wheel loaders, tractors, implements, wheel excavators, crawler excavators, backhoe loaders, forklifts road rollers, light towers, concrete mixers, plate compactor, impact tampers, road cutters, concrete vibrators, and so on.
Engine: YTO4105 G81L
Rated engie power: 119HP(88KW)
Two wheel drive
Withservo pilot system
Rated backhoe bucket capacity : 0.2-0.3CBM
Rated loading bucket capacity: 0.5-0.6CBM
Detailed facture
Specification
Engine Specifications | |
Engine Model | YTO4105 G81L |
Engine power | 119HP(88KW) |
Rated Speed | 2200r/min |
Working Range(mm) | |
Operating weight | 7800kg |
Boom length | 3100 |
Arm length | 2100 |
Max digging radius | 5800 |
Max digging depth | 3400 |
Max dumping height | 6080 |
Max discharge height | 4390 |
Backhoe bucket capacity | 0.2-0.3m3 |
Loading height | 3300 |
Dump clearance | 2500 |
Loading bucket capacity | 0.5-06.m3 |
Rotation angle | 180 |
Hydraulic System | |
Main pump type | Variable piston pump |
Main pump max flow | 63L/min |
Pilot pump type | Gear pump |
Pilot pump max flow | 18L/min |
The main overflow valve(boom/arm/bucket) | 240kgf/cm |
Dimensions(mm) | |
Cabinet width | 1650 |
Cabinet height | 2900 |
Ground clearance | 255 |
Wheel base | 2800 |
Tread | 1930/1650 |
Whole length | 4370 |
Over dimension | 8720*2170*2950 |
1 Packaging Details: one Unit in 40 Container
2 Delivery Detail: 24 workdays after receipt deposit
1)A professional international sales team, which enable us to turn inquiries into final products and export them to numerous countries and regions without barriers;
2) A well managed quality control system to customize on clients requirements. We can design according to customers usage invironment.
3)Unparalleled after sales service
1. How to order?
-After you decide to purchase, we will send you proforma invoice with our bank information, bring this PI to the bank, and ask to make T/T for the deposit. For single set, your machine can be ready within 26 days after we getting the deposit, we will send to the port and deliver to you by sea.
-In case for more handling charges, you can transfer 100% of the payment, we can arrange the products and shipping under your allowance.
-If you still don't understand, please do not hesitate to ask me.
2. Related products?
49kw 53kw 55kw
3. How do we visit you and your factory?
-First of all, welcome you or any appointed agent to vist and inspect our factory.
-You can fly to Shanghai airport, then come from Shanghai railway station to Weifang city. (3 hours)
-You can fly to Qingdao airport, then come from Qingdao railway station to Weifang city. (45 minutes)
-We can pick up you at Qingdao airport or Weifang railway station.
-Please kindly let us know your schedule in details, so that we can arrange everything for you.
5. Why you choose us?
-As manufacturer, our products have excellent quality and competitive price.
-Good after-sales services and 24 months warranty are visible.
-Strictly testing and checking before shipping.
-7 years experience in manufacturing and 7 years exporting experience in Alibaba and Made-In-China.
6. How to contact with me?
-Sales director: kimmy xie
-Mob: 86 13721982293
-Address: Office add: R 2007 rongguanhuafu B Kuiwen, Weifang, Shangdong, China
Factory add: Shanshui Road,Changle,Weifang,Shangdong,China
