ZL16F hydraulic shovel wheel loader used for cleaning snow:
*engine with preheater for start
*joystick and quick change optional
*CE approved
Map Power Company is a real factory supply wheel loaders such as ZL08, ZL10, ZL12, ZL16, ZL20, ZL30,ZL16with long arm, ZL50, coal loader, long-armed loader, high-efficiency loader.
shovel loader ZL16F For Cleaning Snow
Multi-function wheel loader 1.6ton can be with snow blade, snow bucket, pallet fork, grapple fork, 4 in 1 bucket, road sweeper, snow blower, light bucket and ect.
shovel loader 1.6ton equipment: hydraulic 265 torque converter, 3-way pilot control, adjustable steering wheel, quick change, luxury seat, new cabin with warm and new engine cover, bigger tire
shovel loader applications:
The ZL16/916 wheel loader is used for loading or transporting sands, coal residue, sandstone and so on for road construction, environmental sanitation, small and medium-sized civil engineering, or in the station, warehouses and other places. The wheel loader can be combined with auto truck of 3-5tons to load and unload goods, and can conduct bulldozing, digging hoisting and other operations.
Advantages to work with us:
1)A professional international sales team, which enable us to turn inquiries into final products and export them to numerous countries and regions without barriers;
2) A well managed quality control system to customize on clients requirements. We can design according to customers usage inviorenment.
3)Unparalleled after sales service
If you have demand please let me know, I will offer best price for you.
Detailed specification of ZL16F wheel loader:
|
Mini Wheell Loader Specifications (1.6T wheel loader) Overall Dimension | |||
1 |
Length(with bucket on ground) |
4900(mm) |
|
2 |
Bucket width |
2070(mm) |
|
3 |
Height(To the top of the cab) |
2740(mm) |
|
4 |
Wheel base |
2150(mm) |
|
5 |
Tread |
1500(mm) |
|
6 |
Min. ground clearance |
342(mm) |
|
Main Technical Specification | |||
1 |
Rated load |
1600(Kg) |
|
2 |
Operating weight |
4300KG |
|
3 |
Rated bucket capacity |
1.0(CBM) |
|
4 |
Max. breakout force |
45KN |
|
5 |
Max. dump clearance |
2850(mm) |
|
6 |
Dump reach |
960(mm) |
|
7 |
Dump angle at any position |
≤40 |
|
8 |
Digging depth(with bucket bottom horizontal) |
146(mm) |
|
9 |
9 Max. turning radius |
|
|
|
(1) Outside of bucket |
4850(mm) |
|
(2) Outside of rear wheel |
4675(mm) |
||
10 |
Pivot angle frame |
38+ |
|
11 |
Oscillating angle of rear axle + |
±11° |
|
12 |
Lifting time of bucket |
≤5.9(sec.) |
|
ZL16F with standard teeth bucket:
ZL16F snow wheel loader with snow blade:
ZL16F wheel loader with light bucket:
ZL16F mini wheel loader:
