Wheel LOADER 3TON WITH DEUTZ engine optional
Wheel loader brief introduction:
1. Using direct injection diesel engine as power, with easy startup and low oil consumption
2. Using special drive axle, with strong ability to overcome obstacle
3. Chassis uses hinged structure, with small turning radius and flexible turning, which applies to the operation in narrow space
4. Widely applying to the construcction of agricultural engineering and small and medium building such as road, coal mine, brickyard, urban construction, kiln factory, stone material factory, prefabricated cement parts factory, etc.
Main Specifications
Overall dimension(mm) |
7120x 2460 x 2950 |
Rated loading weight(kg) |
3,000kg |
Rated bucket capacity(m3) |
1.5-2.0 |
Operating weight |
9800kg |
Wheel base(mm) |
2600 |
Tread(mm) |
1800 |
Tires |
17.5-25 |
Min ground clearance(mm) |
300 |
Dump clearance(mm) |
2800-3100 |
Dump reach(mm) |
1160 |
Min turning radius(m) |
5.1 |
Raising time(s) |
6 |
Total cycling time(s) |
11 |
Max speed(km/h) |
22 |
Engine Model |
4DW81-37 |
Rated Power(kw) |
92 |
Rated Speed |
2200r/min |
Max breakout force(kn) |
96 |
Max. drawing force(kn) |
75 |
