Wheel Loader ZL16F Car Carrier Special With Forks CE Approved

Wheel Loader ZL16F Car Carrier Special With Forks CE Approved thumbnail-1
Wheel Loader ZL16F Car Carrier Special With Forks CE Approved photo-1
US$ 10,000 - 12,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
Wheel loader
Place of Origin:
Shandong, China
Model Number:
ZL16F
Contact Supplier Request Quote Chat Now
Sand Washing CO.,LTD
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Wheel loader
Place of Origin Shandong, China
Model Number ZL16F
Type Mini Loader
Certification CE
After-sales Service Provided Engineers available to service machinery overseas
Warranty 1 year after arrived the destination port
Condition New
Dimension(Long * Breadth * High) 4900X2070X2740MM
Moving Type Wheel Loader
Rated Load 1600KGS

Performance Features of ZL16F Wheel Loader:

  1. The wheel loader uses a hydro-mechanical transmission which can make full use of engine power and can have an automatic variable transmission according to the external resistance. It avoids power failure of the engine due to the suddenly increased external load. The wheel loader can absorb and eliminate the vibration and impact of external load on engine. It protects the drive system and engine, increases the service life, facilitates the operation and achieves higher economical and production efficiency.
  2. The wheel loader uses a central articulated frame and load sensing hydraulic steering gear. The machine can achieve a short turning radius and superposition of the front and rear tracks upon turning (this will ensure safe driving.)The wheel loader has the advantages of easy operation on narrow sites, flexible operation, safety, convenient maintenance and so on.
  3. The wheel loader uses four-wheel drive, low-pressure wide base off-road tires and an oscillating rear axle, so it has sound off-road performance, good traffic ability and larger traction.
  4. The wheel loader is equipped with a single-pipe type hydraulic four-wheel brake.
  5. The wheel loader has a fully enclosed cab and the seats have the functions of vibration reduction and easy adjustment. The machine offers the driver a comfortable drive and wide view.

Detailed specification of ZL16F wheel loader:

<

rated loading 1600kg
overall weight 4800kg
rated bucket capacity 0.9m
maximum tractive force 54KN
maximum breakout force 45.4KN
maximum grade ability 30
maximum dump height 2850mm
maximum dump reach 752mm
overall dimension(L*W*H) 5200*1950*2740mm
minimum turning radius 5251mm
model WEICHAI4102
type vertical, in-line, water cooled, 4-stroke diesel engine
No. of cylinder-bore/stroke 4-105*125mm
rated power 47kw 2200rpm
maximum torque 270N.m
min fuel-consume ratio ≤243g/kw·h
torque converter YJ265A
gearbox mode countershaft power-shift
gear shift 2 forward shift 2 reverse shift
maximum speed 24km/h
main reducing spiral Circular Arc Bevel gear, single stage
decelerating mode single stage planetary type
wheel base(mm) 2400mm
wheel tread 1640mm
ground clearance 310mm
system working pressure 16MPa
boom lifting time 4.8s+0.2s
total time 9.2s+0.5s
fuel tank capacity 80L
function of leveling automatically yes
service brake air assist disc brake on 4 wheel
parking brake flexible shaft operated external drum
type specification 16/70-16
front tyre pressure 0.22MPa
rear tyre pressure 0.18MPa



· Wheel loader with snow bucket, 4 in 1 bucket, plate forks, wood forks, snow blade, snow blower, road sweeper.ect are available

· adjustable design are accepted, for example: bigger tires, luxury cabin, cabin with air conditioner, adjustable for the gearshift, adjustable steering wheel seat.ect

· Use the Weichai4102 diesel engine, with full hydraulic steering system.



ZL16F wheel loader:

 wheel loader ZL16F car carrier special with forks CE approved

ZL16F shovel wheel loader

wheel loader ZL16F car carrier special with forks CE approved

ZL16F hydraulic wheel loader:

wheel loader ZL16F car carrier special with forks CE approved

ZL16F wheel loader with snow blade

wheel loader ZL16F car carrier special with forks CE approved
