Help CenterFull Hydraulic Transmission CE Approved Professional Wheel Loader ZL12
Related Products
-
2500kgs Pay Loading Weight Wheel Loader With Cummins EngineUS$ 13,330 - 18,890MOQ: 1 Unit -
China 2ton Wheel Loader for SaleUS$ 13499.00 - 15.00MOQ: 1 Unit
-
Mini Articulated Transport LoaderUS$ 5,300 - 7,090MOQ: 1 Unit
-
1.2ton Hydraulic ZL12F Mini LoaderUS$ 6,900 - 9,900MOQ: 1 Unit
-
ZL08 Articultaed Mini Garden LoaderUS$ 7090.00 - 15.00MOQ: 1 Piece
1.Hydraulic quick change
2.Pilot control
3.Tire 1100-16
4.Air conditioned cabin
Mini Wheel Loader ZL12F with CE
Equip with :3-valve pilot control,Euro III engine,adjustable steering wheel,quick hitch,
luxury sea Wheel loader ZL12 with EURO III engine
1.Hydraulic quick change
2.Pilot control
3.Tire 1100-16
4.Air conditioned cabin t,new cabin with warm and new engine hood,12-16.5
Features
Fully hydraulic steering,power shift hydraulic operated working device.The full hydraulic steering system is smooth in operation, stable and reliable in performance
Optional attachments like pallet fork,grass fork,snow blade and snow buckets available to all materials.
High boom lifting capacity for heavy duty handing jobs.
The bucket is equipped with automatic leveling device, so that the operation is easier.
Big tractive force and traction device at the rear end, which meet more needs.
Wheel loader model |
ZL12F |
|
Engine Details |
Model |
Changchai 4L68 |
Engine Type |
In-line arrangement, Water cooled,4 cycle diesel engine |
|
Rated Power |
37kw |
|
Rated Speed |
2200rpm |
|
Bucket |
Bucket Capacity |
0.65m³ |
Bucket Type |
Heavy-duty bolt on teeth |
|
Rated Load |
1000kg |
|
Total Weight |
2500kg |
|
Overall Dimensions |
Overall Length |
4750mm |
Overall Height |
2700mm |
|
Overall Width |
1720mm |
|
Max. Discharge Height |
2200mm |
|
Wheel Base |
1580mm |
|
Tread |
1400mm |
|
Operating |
Transmission System |
Hydraulic converter |
Steering system |
Articulated Frame with Hydraulic |
|
Min. Turning Radius |
3900mm |
|
Transmission |
Hydraulic convertor |
|
Brake System |
Service Brake |
Four wheel Hydraulic spread-shoed |
Parking Brake |
Hand Operated |
|
Tire |
8.25-16 |
|
Optional Accesssory
