China 2ton Wheel Loader for Sale

China 2ton Wheel Loader for Sale thumbnail-1
China 2ton Wheel Loader for Sale thumbnail-2
China 2ton Wheel Loader for Sale thumbnail-3
China 2ton Wheel Loader for Sale thumbnail-4
China 2ton Wheel Loader for Sale thumbnail-5
China 2ton Wheel Loader for Sale thumbnail-6
China 2ton Wheel Loader for Sale photo-1
China 2ton Wheel Loader for Sale photo-2
China 2ton Wheel Loader for Sale photo-3
China 2ton Wheel Loader for Sale photo-4
China 2ton Wheel Loader for Sale photo-5
China 2ton Wheel Loader for Sale photo-6
US$ 13499.00 - 15.00 MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
MAP
Place of Origin:
Shandong, China
Model Number:
ZL20F
Contact Supplier Request Quote Chat Now
Sand Washing CO.,LTD
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name MAP
Place of Origin Shandong, China
Model Number ZL20F
Type Mini Loader
Certification ce, CE
After-sales Service Provided Engineers available to service machinery overseas
Warranty 12months
Condition New
Dimension(Long * Breadth * High) 5600X2100X2850MM
Moving Type Wheel Loader
Rated Load 2000kgs

Product Description

  2.0ton wheel loader



1)Dumping height:3100mm
2)Loader Bucket :1.2CBM
3)17/16-20 Tire
4)Joystick and Pilot control

Wheel Loader CS920  WITH CE





Features 2.0 ton heavy machine tractor loader

*Fully hydraulic steering,power shift hydraulic operated working device.

*The full hydraulic steering system is smooth in operation, stable and reliable in performance

*Optional attachments like pallet fork,grass fork,snow blade and snow buckets available to all materials.

*High boom lifting capacity for heavy duty handing jobs.

*The bucket is equipped with automatic leveling device, so that the operation is easier.

 *Big tractive force and traction device at the rear end, which meet more needs.



 Detailed Specification:



Performance

1

rated loading

2000kg

2

overall weight

5800kg

3

rated bucket capacity

1.2m3

4

maximum tractive force

54KN

5

maximum breakout force

45.4KN

6

maximum grade ability

30

7

maximum dump height

3000mm

8

maximum dump reach

752mm

9

overall dimension (L×W×H)

5600×2100×2850mm

10

minimum turning radius

5251mm

Engine

11

model

4105

12

type

Vertical, in-line, water cooled, 4-stroke diesel engine

13

No. of cylinder-bore/stroke

4105×125mm

14

rated power

58kw2200r/min

15

maximum torque

270N.m

16

min fuel-consume ratio

≤243g/kw.h

Transmission system

17

torque converter

YJ280A

18

gearbox mode

Countershaft power-shift

19

gear shift

2 forward shift  2 reverse shift

20

maximum speed

24km/h

Drive axles

21

main reducing spiral



Circular Arc Bevel gear, single stage

22

decelerating mode

Single stage planetary type

23

wheel base (mm)

2400mm

24

wheel tread

1640mm

25

ground clearance

310mm

Hydraulic system

26

system working pressure

16MPa

27

boom lifting time

4.8s±0.2s

28

 total time

9.2s±0.5s

29

fuel tank capacity

80L

30

function of leveling automatically

 yes

Brake system

31

service brake

air assist disc brake on 4 wheels

32

parking brake

flexible shaft operated external drum

Tyre

33

type specification

16/7020

34

front tyre pressure

0.22Mpa

35

rear tyre pressure

0.18Mpa









China 2ton wheel loader for saleChina 2ton wheel loader for sale






China 2ton wheel loader for sale
China 2ton wheel loader for sale









Attachments avaliable



China 2ton wheel loader for saleChina 2ton wheel loader for sale





Our Services



Warranty and payment term



1) Payment terms: 30% T/T deposit,balance before shipment.



2) Delivery time: 25-30 days after we receive the deposit



3) Warranty period:1 year or 2000 working hours which comes first.





Company Contact Information





Company Name:

Weifang Map Import & Export Co., Ltd.



Operational Address:

Room 1-2-2007, No. 8580, Dongfeng East Street, Kuiwen Dist., Weifang, Shandong, China



Telephone:

0086-536-8502890



Website:



Website on :



Store:

/store/904969







Packaging & Shipping







Packing:Nude packing



Shipping: 2sets in 40HQ






FAQ

  China 2ton wheel loader for sale
