mini front wheel loaderZL08F
*Transmission:Manual
*drived by shaft
*With CE
Specification
Engine Details | |
Model |
L28 |
Engine type |
In-line arrangement, water-cooled, four-cycle diesel Engine |
Rated Power |
28HP |
Rated Speed |
2200 r/min |
Min.ful consumption |
235 g/kw.h |
Bucket | |
Bucket Capacity |
0.3m3 |
Bucket type |
Heavy-duty bolt on teeth |
Rated Load |
800 kg |
Operating Weight |
2100 kg |
Overall Dimensions | |
Overall Length |
4750 mm |
Overall Height |
2650 mm |
Overall Width |
1700 mm |
Max. discharge height |
2700 mm |
Max discharge distance |
600mm |
Wheel base |
1580 mm |
Tread |
1400 mm |
Operating Specifications | |
Steering System |
Articulated Frame with hydraulic power steering |
Min Turning Radius |
4500 mm |
Transmission System |
Manual clutch |
Brake System | |
Service Brake |
Four Wheel Hydraulic spread-shoed brake |
Parking Brake |
Hand operated |
Tyre |
825-16 |
