Construction Machinery Cheap 5 Ton SEM 655D Loaders

Construction Machinery Cheap 5 Ton SEM 655D Loaders photo-1
Construction Machinery Cheap 5 Ton SEM 655D Loaders photo-2
Construction Machinery Cheap 5 Ton SEM 655D Loaders photo-3
Construction Machinery Cheap 5 Ton SEM 655D Loaders photo-4
Construction Machinery Cheap 5 Ton SEM 655D Loaders photo-5
Construction Machinery Cheap 5 Ton SEM 655D Loaders photo-6
Construction Machinery Cheap 5 Ton SEM 655D Loaders photo-7
US$ 53200.00 - 53600.00 MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
Map Power
Place of Origin:
Shandong, China
Type:
Front Loader
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Map Power
Place of Origin Shandong, China
Type Front Loader
Certification CE
Warranty 1 year
Condition New
Dimension(Long * Breadth * High) 7836*3010*3300mm
Moving Type Wheel Loader

Heavy Duty Construction Machinery Cheap 5 ton SEM 655D loaders

*Rated loading weight: 5,000kg
*Rated capacity: 3.0cbm
Construction Machinery Cheap 5 ton SEM 655D loaders





SEM 655D Wheel loader Specifications

Rated Load

5000 kg

Operating Weight with Standard Bucket

16700 kg

Bucket Capacity

2.7-4.5 m³

Wheel Base

3200 mm

Overall Dimension (mm)

8085*2963*3463

Engine

Model

 WD10G

Rated Power

162 kW

Rated Speed

2000 r/min

Displacement

9.726 L

Operating Specifications

Breakout Force

168 kN

Dump Clearance

3058 mm

Articulated Angle

38±1 °

Implement Hydraulic

Implement System Type

Twin pump flow merging hydraulic system

Boom Raise Time

5.13 s

Hydraulic Cycle Time

9.5 s

System Presure Setting

17 Mpa

Transmission

Transmission Type

Countershaft, power shift

Transmission Gears

F4/R4

Torque Converter Type

Sigle stage 3 elements

Maker & Type

SEM TR200

Forward I/ Reverse I

7.8/7.8 km/h

Forward II/ Reverse II

15/15 km/h

Forward III/ Reverse III

22/22 km/h

Forward IV/ Reverse IV

39/39 km/h

Brake System

Service Brake

Dry & caliper, air to oil control

Parking Brake

Drum type shoe brake,
           spring applied & oil released

Steering System

System Type

Flow amplifying

Steering Pump Type

Gear pump

System Presure Setting

16 Mpa

Steering Angle (L/R)

38±1 °

Axle

Main Drive Type

Spiral bevel gear, single stage

Final Drive Reduction Type

Planetary type, singe stage

Rear - Oscillating +/-

±11 °

Tires

Size

23.5-25

 Construction Machinery Cheap 5 ton SEM 655D loaders

Cabin Inside Picture



 Construction Machinery Cheap 5 ton SEM 655D loaders





Construction Machinery Cheap 5 ton SEM 655D loadersConstruction Machinery Cheap 5 ton SEM 655D loadersConstruction Machinery Cheap 5 ton SEM 655D loadersConstruction Machinery Cheap 5 ton SEM 655D loadersConstruction Machinery Cheap 5 ton SEM 655D loadersConstruction Machinery Cheap 5 ton SEM 655D loaders



 Construction Machinery Cheap 5 ton SEM 655D loadersConstruction Machinery Cheap 5 ton SEM 655D loaders



Construction Machinery Cheap 5 ton SEM 655D loaders





Construction Machinery Cheap 5 ton SEM 655D loaders
Construction Machinery Cheap 5 ton SEM 655D loaders
