Best Seller Flexible Rubber Suction Hose Made In China
Construction
1. Material: EPDM/NBR synthetic rubber
2. Size: 32mm~356mm
3. Length: 6m~20m
4. Work Pressure: 3Bar
5. Certification: ISO 9001-2000
6. Reinforcement: with steel wire, and fabric inserted
7. Temperature: -30~+80’C
Application
The hose is suitable for conveying water for industrial use.(Mining, construction, factory drainage system.)
Features
It has solid structure and good bending performance. The hose has the double properties of bearing both the positive and negative pressure, can be used normally under the pressure 60-80Kpa, no deformation, no delamination, has good adaptability to different environment.
Technical Parameter
Inside Diameter (mm) |
Outside Diameter (mm) |
Working Pressure (bar) |
Layer |
Length |
||
Size |
Tolerance |
Size |
Tolerance |
|||
32 |
±1.2 |
40 |
±1.2 |
3 |
3 |
10m |
38 |
±1.2 |
46 |
±1.2 |
3 |
3 |
10m |
51 |
±1.2 |
59 |
±1.2 |
3 |
3 |
10m |
64 |
±1.5 |
72 |
±1.5 |
3 |
3 |
10m |
76 |
±1.5 |
84 |
±1.5 |
3 |
3 |
10m |
89 |
±1.5 |
97 |
±1.5 |
3 |
4 |
10m |
102 |
±1.5 |
110 |
±1.5 |
3 |
4 |
10m |
127 |
±2.0 |
137 |
±2.0 |
3 |
4 |
10m |
152 |
±2.0 |
162 |
±2.0 |
3 |
4 |
10m |
203 |
±2.5 |
213 |
±2.5 |
3 |
4 |
10m |
254 |
±2.5 |
265 |
±2.5 |
3 |
5 |
10m |
305 |
±2.5 |
320 |
±2.5 |
3 |
8 |
10m |
356 |
±2.5 |
372 |
±2.5 |
3 |
10 |
10m |
Packing details: woven bag packing or according to customer's requirment
Delivery detail: within 15 days after receive the deposit
Main products manufactured by us:
1)Steel Wire Braid Hydraulic Hose Series:
SAE 100 R1AT/DIN EN 853 1SN, SAE 100 R2AT/ DIN EN 853 2SN;
SAE 100 R1A/ DINEN 853 1 ST, SAE100 R2A/ DIN EN 853 2ST
DIN-EN 857 1SC,DIN-EN 857 2SC;
SAE 100 R5, SAE100 R16, SAE 100 R17
2) Steel Wire Spiral Hydraulic Hose Series:
SAE 100R9, SAE 100R12, SAE 100R13, SAE 100R15,DIN EN856 4SP , DIN EN856 4SH
3) Textile Braid Hydraulic Hose: SAE 100 R3, SAE 100 R6
Q: Can you produce customized goods ?
A: Yes, the size, diameter and length can be produced as per client's requirements.
Q: Can you print words on products as per client's requirement?
A: Yes, make label according to your exact requirement.
Q: Can you do business via Ali Online Transaction?
A: Yes, we can make the deal through AOT.
Q: What is your payment terms?
A: T/T, L/C at sight or Paypal.
Q: Do you accept OEM?
A: Yes, OEM or ODM are both OK.
Q: Where is your nearest loading port ?
A: Tianjin Xingang, China.
Q: How can you guarantee the quality or any warranty?
A: If any quality problems during use, all the products can be returned
or according to consumer's requests.
