Techwin Glass washing and drying machines
Specifications for Techwin Glass washing and drying machines TWQX-2500B
Max. Glass Size |
2600 |
MM |
Min. Glass Size |
400*400 |
MM |
Glass Thickness |
3~25 |
MM |
Speed |
0.6~7 |
M/min |
Power |
35 |
KW |
Brush |
3 |
pair |
Brush Shaft Diameter |
170 |
MM |
Roller Diameter |
80 |
MM |
Water Tank |
3 |
unit |
Air Knives |
2 |
pair |
Table Height |
850±50 |
MM |
Overall Dimension(L*W*H) |
6480*4530*3200 |
MM |
Net Weight |
5200 |
KG |
PRODUCT CHARACTERISTICS:
1.Through adopting the flat structure with concise and perfect appearance design.
2.The enter section has stainless ponding sink, the rubber covered roller could move automatic; the pre-cleaning system is equipped with high pressure water jetting, so as to improve the cleaning function.
3.Three level cleaning structure and 3 pairs of brush roller allocation in which the front of brush can be elevated the cylinder; then use the third to clean common coating film, hard low-e glass and coated glass.
4.Gear convey of the transmission is smooth and reliable. the transmission system is displayed digital and used drives to adjust the speed ;It's more useful for connection, Double edging production line, Glazing line, the insulating glass and Safety glass product line, so on.
5.Adopting advanced technology for the multilevel nozzle which is saving energy and high efficiency
6.The shelves of electric control cleaning section and air drying section which can be lifting, the maxima degree is up to 450mm.It's convenient for maintenance and inspection. Glass thickness could be shown by digital, available with accurate adjustment and observation.
7.We can offer the efficient cleaning and drying machine with speed 12 meters per minute as customer's requirement.
WHY YOU CHOOSE US?
1. Any information on your company?
Techwin is synonymous of quality since its beginning. Specialized in the field of manufacturing horizontal and vertical glass washers, glass drilling machines, automatic glass conveyers, multi-functional glass cutting tables, Glass loading/off-loading production lines, PVB laminated glass processing lines. We have years of OEM experience for some famous glass machinery companies in China. We have provided machines to more than 20 overseas countries including: US, Australia, New Zealand, Malaysia, Venezuela, India, Russia, Turkey, Iran, Pakistan, Tunis ...
Our list of satisfied clients is growing monthly.
2. What’s the customer service?
1).Reply within 24 hours.
3).24 hours for after-sale service.
4).More than 20 years experience in this field.
5).Fluent English, communication barrier free.
3. What’s the guarantee?
1)The whole set of machine warranty period is 1 year.
2).24 hours technical support by email or calling.
3).English manual and tutorial. Free training provides. We could dispatch engineer overseas, the buyer should pay the fly ticket and accommodation
4).We will provide the consumable parts at an agency price.
4. Why your price is higher than another company or factory?
We use world famous brands of electrical parts with longer usage life. Our strong engineers have more than 10 years of R&D experience in this field, we always use mature structure/design of our machines.
5. How long is the delivery time?
Normally its 20 to 45 days.
6. How's the payment?
T/T: 30% T/T deposit, balance 70% before shipment ; L/C; Trade Assurance.
7. If I want to use some certificates to pay less tax for importing your machines,can you help me?
We can make the different Certification of Origin, it will make you to pay the less tax if you import our machines.
8. Can you make the machine according to my requirements?
Yes, of course. Customerized service is provided.
Agents Wanted: We are finding agents all over the world.
Any question, please email me or call me directly or chat with me online.
Contact us right now to get a big discount!!
