Copy routing machine for PVC Profile
Equipment Features:
1. Used for routing holes and slots in horizontal and vertical directions.
2. Pneumatic clamping, high speed, milling and atomized cooling.
3. It can also make copy routing in vertical directions.
Technical Parameters:
Power supply |
380v 50Hz |
Operation air pressure |
0.4~0.6MPa |
Air consumption |
30L/min |
Input power |
0.75kw |
Air consumption |
30L/min |
copy-routing range |
90x290mm |
Motor Rotating speed |
2800r/min |
Contour dimension Including the length of carriage |
1000×1130×1500mm(L×W×H ) |
Weight |
170KG |
1.Note:
Payment: Telex Transfer (T/T), 30% be paid after confirming the order and the rest 70% is effected while delivering the goods.
Port of Loading: Qingdao, China
Delivery Time: During 20-35 days after we receive your first payment.
